About the product
HPE Networking Instant On AP22 Indoor Access Points deliver affordable, business-grade 802.11ax Wi-Fi for high performance, high density small business environments. Business-grade capabilities are designed to meet the growing number of mobile, IoT, and security needs. The compact form factor of the HPE Networking Instant On AP22 Indoor Access Points (AP) delivers multi-user capabilities and a maximum aggregate peak data rate of 1.2 Gbps for high-definition video streaming and cloud application requirements. Everything from mounting hardware to easy-to-use web and mobile app management tools, and business-grade software features are included – no extra charge or need for external controllers.
Technical Specifications
| Primary Information | |
| Product Description: | HPE Networking Instant On AP22 (RW) - wireless access point - Bluetooth, Wi-Fi 6 |
| Device Type: | Wireless access point |
| Form Factor: | Wall / ceiling mountable - indoor |
| Data Link Protocol: | Bluetooth, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, IEEE 802.11ax (Wi-Fi 6) |
| Frequency Band: | 2.4 GHz, 5 GHz |
| Performance: | Maximum data rate (5 GHz): 1.2 Gbps ¦ Maximum data rate (2.4 GHz): 574 Mbps |
| Included Accessories: | Wall/ceiling rail mounting clip |
| Power Over Ethernet (PoE) Supported: | PoE |
| Dimensions (WxDxH): | 6.3 in x 6.3 in x 1.5 in |
| Weight: | 17.64 oz |
| Manufacturer Warranty: | 1-year warranty |
| General | |
| Device Type: | Wireless access point |
| Ruggedized Design: | Indoor |
| Width: | 6.3 in |
| Depth: | 6.3 in |
| Height: | 1.5 in |
| Weight: | 17.64 oz |
| Networking | |
| Form Factor: | Wall / ceiling mountable |
| Connectivity Technology: | Wireless |
| Line Coding Format: | 1024 QAM |
| Data Link Protocol: | Bluetooth, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, IEEE 802.11ax (Wi-Fi 6) |
| Spread Spectrum Method: | OFDMA |
| Network / Transport Protocol: | PPPoE |
| Frequency Band: | 2.4 GHz, 5 GHz |
| Performance: | Maximum data rate (5 GHz): 1.2 Gbps ¦ Maximum data rate (2.4 GHz): 574 Mbps |
| Status Indicators: | Status |
| Features: | Firewall protection, manageable, static IP mode, Trusted Platform Module (TPM), reset button, Low Density Parity Check (LDPC), Transmit Beam-forming (TxBF) ready, security lock slot (cable lock sold separately), Advanced Cellular Coexistence (ACC), MU-MIMO technology, 2x2 MIMO technology, Bluetooth (BLE) clients support, Target Wait Time (TWT), Smart Mesh technology, BSS Coloring |
| Encryption Algorithm: | WPA2, WPA3 |
| Compliant Standards: | IEEE 802.11b, IEEE 802.11a, IEEE 802.3af, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, IEEE 802.11ax, Wi-Fi CERTIFIED 6 |
| Antenna | |
| Antenna: | Internal |
| Directivity: | Omni-directional |
| Internet of Things (IoT) | |
| Internet of Things (IoT) Compatible: | Yes |
| Communications Technology: | Bluetooth Low Energy (LE) |
| Expansion / Connectivity | |
| Interfaces: | 1 x Ethernet 1000 (uplink) |
| Miscellaneous | |
| Included Accessories: | Wall/ceiling rail mounting clip |
| Cables Included: | 1 x network cable |
| MTBF: | 91 years |
| Compliant Standards: | UL 2043, EN 60601-1-2, EN 60601-1-1 |
