TS 15MM U.2 P5620 6.4TB 2.5 MIXEDUSE NVMEPCIE 4.0 SSD NC/NR

The ThinkSystem P5620 Mixed Use NVMe SSDs are advanced data center SSDs optimized for mixed read-write performance, endurance, and strong data protection for Lenovo servers. With a PCIe 4.0 x4 interface, they are designed for greater performance and endurance in a cost-effective design, and to support a broader set of workloads. Now with SED encryption as standard, these drives help ensure data security, even when the drive is removed from the server.

This product guide introduces the drives and describes their features and specifications, and provides compatibility information. This guide is intended for technical specialists, sales specialists, sales engineers, IT architects, and other IT professionals who want to learn more about the P5620 SSDs and consider their use in IT solutions.

• Based on the Solidigm D7-P5620 SSDs (formerly known as the Intel D7-P5620 SSDs)
• PCIe 4.0 connection for each NVMe drive
• Also supports PCIe 3.0 host connection for servers with first and second-generation Intel Xeon Scalable processors or with PCIe 3.0 NVMe switch adapters
• Compliant with Trusted Computing Group Opal 2.01 Security Subsystem Class cryptographic standard (TCG Opal 2.01 SSC)
• Intel 144-layer TLC 3D NAND Flash Memory
• Ultra-low I/O latency, with a read latency as low as of 9 µs and write latency as low as 12 µs
• Suitable for mixed read-write workloads
• Available in capacities up to 12.8 TB
• Variable sector size and end-to-end data-path protection
• Enhanced power-loss data protection
• Thermal throttling and monitoring
• SMART health reporting
