About the product
The ThinkSystem P5520 Read Intensive NVMe SSDs are general-purpose yet high-performance drives with a PCIe 4.0 x4 interface. They are designed for greater performance and endurance in a cost-effective design, and to support a broader set of workloads. Now with SED encryption as standard, these drives help ensure data security, even when the drive is removed from the server.
The P5520 SSDs are based on Intel-developed controller, firmware, and 144-layer TLC Intel 3D NAND technology. Rigorous qualification and compatibility testing by Lenovo ensures a highly reliable SSD.
The P5520 SSDs are based on Intel-developed controller, firmware, and 144-layer TLC Intel 3D NAND technology. Rigorous qualification and compatibility testing by Lenovo ensures a highly reliable SSD.
- The high-read speed of 7270.40 MB/s maximizes system performance and saves time while you are doing complex tasks
- With the high-write speed of 3788.80 MB/s, get a quick response when updating or transferring files
- With 15.36 TB capacity you have ample space for storing millions of images, hundreds of hours of video or for music lovers, up to a million songs
- PCI Express NVMe 4.0 x4 interface provides quick data transfer and greater throughput
Technical Specifications
| Network & Communication | |
| Wireless LAN | No |
| Technical Information | |
| Storage Capacity | 15.36 TB |
| Interfaces/Ports | |
| Drive Interface | U.2 |
| Drive Interface Standard | PCI Express NVMe 4.0 x4 |
| Miscellaneous | |
| Package Contents |
|
| Compatibility |
|
| Device Supported | Server |
| Environmentally Friendly | Yes |
| Environmental Compliance | Waste Electrical and Electronic Equipment Directive (WEEE) |
| Restriction of Hazardous Substances (RoHS) | |
| Drive Performance | |
| Maximum Read Transfer Rate | 7270.40 MB/s |
| Maximum Write Transfer Rate | 3788.80 MB/s |
| Random 4KB Read | 1000000IOPS |
| Random 4KB Write | 200000IOPS |
| Endurance (DWPD) | 1 |
| Endurance (TBW) | 28672 TB |
| Endurance Type | Read Intensive |
| Physical Characteristics | |
| Hot Swappable | Yes |
| Weight (Approximate) | 5.15 oz (146 g) |
| Drive Type | Internal |
| Form Factor | 2.5" |
| Height | 0.59" (15 mm) |
| Width | 2.76" (70 mm) |
| Depth | 3.94" (100 mm) |
| General Information | |
| Product Type | Solid State Drive |
| Manufacturer Part Number | 4XB7A76779 |
| Manufacturer Website Address | http://www.lenovo.com |
| Packaged Quantity | 1 |
| Manufacturer | Lenovo Group Limited |
| Product Name | ThinkSystem 3.5" U.2 P5520 15.36TB Read Intensive NVMe PCIe 4.0 x4 HS SSD |
| Product Series | P5520 |
| Brand Name | Lenovo |
