Computer Accessories
Expected delivery 3 to 7 business days (exceptions applied)
Panasonic
Panasonic Docking Station
Panasonic Docking Station
Panasonic Docking Station - for Notebook/Tablet PC - 2 x USB Ports - 2 x USB 3.0 - 1 x RJ-45 Ports - Network (RJ-45) - 1 x HDMI Ports - HDMI - VGA - Docking - Ethernet
VPN:7160-1265-02 SKU:AC685958 UPC:Loading
Couldn't load pickup availability
Volume discount available - Ask for quote..
View full details
Recently Viewed
Panasonic Docking Station
Product information summary

About the product
Engineered for demanding work environments in utility, public safety, and material handling
This Gamber-Johnson Laptop docking station is designed to work with the Panasonic Toughbook® 20 and G2 computers with an attachable keyboard. Position the computer in tablet or laptop mode and remove the computer to use outside your mobile office. The docking station offers full port replication to support a mobile office environment and the keyed lock provides additional security to protect your investment.
- Compatible with the Toughbook 20 and G2 computers with an attachable keyboard
- Panasonic Certified electronics
- Spring-loaded cover protects docking connector when computer is not docked, automatically retracts for superior protection
- Special docking connector pin protection - helps to prevent accidental pin damage by providing additional protection around and in between each docking pin
- Can be used in either laptop or tablet orientation.
- Composite/aluminum design for reduced weight and durability
- Designed with rounded edges to enhance personal safety
- Rear-facing I/O ports; integrated cable strain relief and cable management system
- Access to all notebook control buttons and ports while the notebook is docked
- Keyed lock for theft deterrence. NOTE: The lock secures the Toughbook 20 keyboard and tablet, but secures only the keyboard for the G2.
- VESA 75 mm mounting pattern
- 3-year limited warranty
Technical Specifications
Network & Communication | |
Ethernet Technology | Ethernet |
Technical Information | |
Device Supported | Notebook/Tablet PC |
Connectivity Technology | Docking |
Features | Key Lock |
Miscellaneous | |
Compatibility | Compatible with the Toughbook 20 and G2 computers with an attachable keyboard |
Environmentally Friendly | Yes |
Brand Compatibility | Panasonic |
Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
Physical Characteristics | |
Weight (Approximate) | 5 lb (2267.96 g) |
Height | 2.99" (76 mm) |
Width | 11.42" (290 mm) |
Depth | 10.91" (277 mm) |
General Information | |
Product Type | Docking Station |
Manufacturer Part Number | 7160126502 |
Manufacturer Website Address | http://www.panasonic.com |
Manufacturer | Panasonic |
Product Name | Docking Station |
Brand Name | Panasonic |
Interfaces/Ports | |
HDMI | Yes |
Number of HDMI Ports | 1 |
VGA | Yes |
Number of Network (RJ-45) Ports | 1 |
Network (RJ-45) | Yes |
Number of VGA Outputs | 1 |
Total Number of USB Ports | 2 |
Number of USB 3.0 Ports | 2 |
Number of RJ-45 Ports | 1 |
