About the product
The Avocor G series is a range of sleek, bezel-less, edge-to-edge interactive displays designed to streamline workplace collaboration. These crystalclear 4K collaboration displays use the latest InGlassTM technology combined with bonded glass to deliver ultra-fast touch performance, supporting up to 20 individual touch points and 4 passive styluses. The G series also provides a 40W crystal-clear audio experience with built-in active microphones
The result is a pixel-perfect user experience and high performance. Available in stunning 65, 75, and 85 sizes, the G series collaboration displays give users an intuitive and interactive experience for participants in the room and meeting equity for those who are remote.Highlights Single Type-C connectivity delivering audio, video, touch, Ethernet and power. Avocor UiQ - smart touch enabled dynamic user interface. Zero parallax optically bonded glass surface for pixel-perfect inking. Wake-on-presence sensons startup the display when movement is detected. InGlass technology supporting palm rejection and 4 passive styluses. Conference rooms | Lecture halls Board rooms Executive offices FUSE - our free-of-charge cloudbased display & software management platform for AV/IT Managers. Montage - wireless screen sharing from any device and instant whiteboarding capabilities
Technical Specifications
| Miscellaneous | |
| Package Contents |
|
| Network & Communication | |
| Ethernet | Yes |
| Ethernet Technology | Ethernet |
| Power Description | |
| Input Voltage | 230 V AC |
| 120 V AC | |
| Touchscreen Information | |
| Touchscreen | Yes |
| Touchscreen Technology | Infrared (IrDA) |
| Multi-touch Screen | Yes |
| Number of Touch Points | 20 |
| Audio | |
| Speakers | Yes |
| Microphone | Yes |
| Number of Speakers | 4 |
| RMS Output Power | 40 W |
| Number of Microphone Array Elements | 4 |
| Physical Characteristics | |
| Weight (Approximate) | 201.28 lb (91300 g) |
| Height | 44.82" (1138.50 mm) |
| Width | 75.96" (1929.50 mm) |
| Depth | 4.61" (117.20 mm) |
| VESA Mount Compatible | Yes |
| VESA Mount Standard | 600 x 400 |
| Software | |
| Operating System | Mac OS X |
| Windows 10 | |
| Windows 8 | |
| Operating System Platform | Windows |
| Mac OS | |
| Linux | |
| General Information | |
| Product Type | Collaboration Display |
| Manufacturer Part Number | 78065654 |
| Manufacturer Website Address | http://www.lenovo.com |
| Manufacturer | Lenovo Group Limited |
| Product Model | AVG-8560 |
| Product Name | AVG-8560 Collaboration Display |
| Product Series | G |
| Brand Name | Lenovo |
| Interfaces/Ports | |
| USB | Yes |
| HDMI | Yes |
| Number of Network (RJ-45) Ports | 1 |
| Network (RJ-45) | Yes |
| Audio Line Out | Yes |
| DisplayPort | Yes |
| Number of HDMI Inputs | 2 |
| Total Number of USB Ports | 9 |
| Number of USB 3.0 Ports | 8 |
| Serial | Yes |
| S/PDIF Out | Yes |
| Display & Graphics | |
| Aspect Ratio | 16:9 |
| Contrast Ratio | 5,000:1 |
| Response Time | 9.50 ms |
| Screen Resolution | 3840 x 2160 |
| Brightness | 500 cd/m² |
| Screen Size | 85" |
| Color Depth | 30-bit |
| Screen Mode | 4K UHD |
| Horizontal Viewing Angle | 178° |
| Vertical Viewing Angle | 178° |
| Scan Format | 2160p |
| Standard Refresh Rate | 60 Hz |
| Display Screen Type | LCD |
| Backlight Technology | Direct LED |
| Display Orientation | Landscape |
