About the product
Technical Specifications
| Network & Communication | |
| Ethernet Technology | Gigabit Ethernet |
| Warranty | |
| Additional Warranty Information | Three-year customer-replaceable unit and onsite limited warranty with 9x5 next business day (NBD). |
| Chipset | |
| Chipset Manufacturer | AMD |
| Chipset Model | PRO-665 |
| Controllers | |
| Controller Type | Serial ATA/600 |
| RAID Supported | No |
| Operating System | |
| Operating System Supported | Red Hat Enterprise Linux 9.5 |
| SUSE Linux Enterprise Server 15 SP6 | |
| Ubuntu 24.04 LTS x64 | |
| Windows Server 2022 | |
| Red Hat Enterprise Linux 9.4 | |
| Physical Characteristics | |
| Weight (Approximate) | 18.87 lb (8560 g) |
| Form Factor | Tower |
| Height | 14.80" (376 mm) |
| Width | 6.69" (170 mm) |
| Depth | 12.44" (316 mm) |
| I/O Expansions | |
| "Number of Internal 2.5"" Bays" | 1 |
| Number of Total Expansion Bays | 4 |
| "Number of 3.5"" Bays" | 3 |
| Total Number of Expansion Slots | 2 |
| Hot Swappable Bays | No |
| Number of SFF Bays | 1 |
| Number of LFF Bays | 3 |
| PCI Express Details | Slot 1: PCIe 3.0 x16 full-height half-length (FHHL) (75W) Slot 3: PCIe 3.0 x1 full-height half-length (FHHL) (25W) |
| Memory | |
| Error Checking | ECC |
| Maximum Memory Supported | 64 GB |
| Signal Processing | Unregistered (Unbuffered) |
| Standard Memory | 32 GB |
| Memory Technology | TruDDR5 |
| Number of Occupied Memory Slots | 1 |
| Memory Clock Speed | 5.60 GHz |
| Total Number of Memory Slots | 2 |
| Power Description | |
| Input Voltage | 120 V AC |
| 230 V AC | |
| Power Source | Power Supply |
| Plug/Connector Type | C13 |
| Number of Power Supplies Supported | 1 |
| Number of Power Supplies Installed | 1 |
| Hot Swappable Power Supply | No |
| Maximum Power Supply Wattage | 300 W |
| Processor | |
| Cache | 32 MB |
| Processor Speed | 3.80 GHz |
| Processor Type | EPYC |
| Processor Model | 4344P |
| Processor Core | Octa-core (8 Core) |
| Processor Manufacturer | AMD |
| Number of Processors Supported | 1 |
| Number of Processors Installed | 1 |
| General Information | |
| Product Type | Server |
| Manufacturer Part Number | 7DH5A01JNA |
| Manufacturer Website Address | http://www.lenovo.com |
| Manufacturer | Lenovo Group Limited |
| Product Model | 7DH5A01JNA |
| Product Name | ThinkSystem ST45 V3 7DH5A01JNA Server |
| Product Line | ThinkSystem |
| Product Series | ST45 V3 |
| Brand Name | Lenovo |
| Interfaces/Ports | |
| HDMI | Yes |
| Number of Network (RJ-45) Ports | 1 |
| Network (RJ-45) | Yes |
| DisplayPort | Yes |
| Remote Management | Yes |
| Total Number of USB Ports | 9 |
| Number of USB 2.0 Ports | 4 |
| Number of DisplayPorts | 2 |
| Remote Management Controller | XClarity Controller (XCC) |
| Miscellaneous | |
| Package Contents |
|
| Security Features |
|
| Environmentally Friendly | Yes |
| Environmental Certification | Electronic Product Environmental Assessment Tool Bronze (EPEAT Bronze) |
| GREENGUARD | |
| Energy Star | Yes |
| Energy Efficiency Certification | ENERGY STAR 4.0 |
| China Energy Conservation Program (CECP) | |
| Energy Efficiency Compliance | Energy-related Products Directive Lot 9 (ErP Lot 9) |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
