Tripp Lite by Eaton NM12-6A1-03M-BL M12 X-Code Cat6a 10G Ethernet Cable, M/M, Bl
Tripp Lite by Eaton NM12-6A1-03M-BL M12 X-Code Cat6a 10G Ethernet Cable, M/M, Bl
VPN:NM12-6A1-03M-BL SKU:CB603986 CPU:37332265388
- Features PoE
- Allows you to access all of the networked data, swiftly and securely
- Features Category 6a cable type
Couldn't load pickup availability
Volume discount available - Ask for quote..
View full details



Recently Viewed
Tripp Lite by Eaton NM12-6A1-03M-BL M12 X-Code Cat6a 10G Ethernet Cable, M/M, Bl
Product information summary

About the product
Cat6a M12 Cable Recommended for Industrial and Other Harsh Environments
This M12 X-Code cable connects 10 GbE networks in wet/humid environments, places subject to vibration and other areas where protection from harsh elements is essential, such as factories, warehouses, recycling plants, airports, railways and machine shops. The circular M12 connectors with 12-millimeter locking thread are especially designed for washdown and corrosive applications, including agriculture, alternative energy, communications, factory automation, measurement and control, robotics, transportation and food/beverage facilities.
IP68 Rating Denotes Resistance to Dust and Water
The IP68 rating means the M12 cable is not only 100% protected against dust, but also able to endure immersion in 1.5 meters of water for up to 60 minutes with no damage or decline in performance.
Supports Power over Ethernet to Save You Money and Give You More Installation Choices
Because this Cat6a cable supports high-power 60W PoE, it can supply the power to operate compatible data, voice, security and audio/video PoE devices, such as surveillance cameras, VoIP telephones and access control devices. This saves you the expense and effort of purchasing, connecting and installing individual power supplies for each device, as well as installing separate power and data cables. It also helps you install PoE devices in areas far away from AC outlets, such as poles or ceilings.
CMR-LP Certified for Cable Installations with Increased Power Levels
UL's Limited Power (LP) certification indicates the NM12-6A1-03M-BL has been evaluated to handle the marked current under installation scenarios without exceeding the temperature rating of the cable. This CMR-LP-certified cable provides a simple way to prepare installations for increased power levels without having to worry about susceptible issues caused by excessive heat.
Colored Blue to Avoid Misidentification That Can Cause Costly Downtime
This Cat6a F/UTP copper cable features a blue PVC jacket that allows easy, fast identification in field devices, controllers and switches and helps prevent the cable from becoming inadvertently disconnected.
- Features PoE
- Allows you to access all of the networked data, swiftly and securely
- Features Category 6a cable type
Technical Specifications
Miscellaneous | |
Country of Origin | Taiwan |
Environmentally Friendly | Yes |
TAA Compliant | Yes |
Physical Characteristics | |
Jacket Material | Polyvinyl Chloride (PVC) |
Product Color | Blue |
Color Family | Blue |
General Information | |
Product Type | Network Cable |
Manufacturer Part Number | NM126A103MBL |
Manufacturer Website Address | https://tripplite.eaton.com/ |
Manufacturer | Eaton Corporation |
Product Model | NM12-6A1-03M-BL |
Product Name | NM12-6A1-03M-BL M12 X-Code Cat6a 10G Ethernet Cable, M/M, Blue, 3 m (9.8 ft.) |
Brand Name | Tripp Lite by Eaton |
Technical Information | |
Cable Length | 9.8 ft (3 m) |
Data Transfer Rate | 10 Gbit/s |
Device Supported | Surveillance Camera |
Network Device | |
VoIP Device | |
Access Control Device | |
Controller | |
Security Device | |
Switch | |
Jacket Type | CMR-LP |
Shielding | Yes |
Features | Temperature Resistant |
PoE++ | |
PoE | |
Moisture Resistant | |
Water Resistant | |
Vibration Resistant | |
Lockable | |
Dust Resistant | |
Damage Resistant | |
Corrosion Resistant | |
Cable Type | Category 6a |
Connector Type on First End | M12-X Network - Male |
Connector Type on Second End | M12-X Network - Male |
American Wire Gauge | 23 AWG |
Connector on First End Details | 1 x M12-X Network - Male |
Connector on Second End Details | 1 x M12-X Network - Male |
Boot Type | Snagless |
