About the product
Powered by the Innogrit IG5220 controller, VisionTek DLX4 2242 M.2 NVMe SSDs offers speed and reliability for professionals. Features Opal 2.0 hardware based Self-Encrypting Technology ensuring that your data remains secure and private. With read speeds up to 5200MB/s and write speeds up to 4775MB/s take your storage to the next level.
- Max Sequential Reads up to 5200MB/s
- Max Sequential Writes up to 4775MB/s
- Max 4K Random Reads up to 370K IOPS
- Max 4K Random Writes up to 288K IOPS
- The high-read speed of 5200 MB/s maximizes system performance and saves time while you are doing complex tasks
- With the high-write speed of 4775 MB/s, get a quick response when updating or transferring files
- Store as many documents, pictures and videos as you need with 1 TB capacity
- With PCI Express 4.0 x4 interface get superb reliability and high-speed data transfer
- With 256-bit AES encryption protect all your valuable data and keep your personal files safe & secure
Technical Specifications
| Interfaces/Ports | |
| Drive Interface | PCI Express NVMe |
| Drive Interface Standard | PCI Express 4.0 x4 |
| Technical Information | |
| Storage Capacity | 1 TB |
| Encryption Standard | 256-bit AES |
| SSD Cache Capacity | 330 GB |
| Drive Performance | |
| Maximum Read Transfer Rate | 5200 MB/s |
| Maximum Write Transfer Rate | 4775 MB/s |
| Random 4KB Read | 370000IOPS |
| Random 4KB Write | 288000IOPS |
| Miscellaneous | |
| Device Supported | Network Controller |
| Certifications & Standards | visiontek Innogrit IG5220 |
| Country of Origin | Mexico |
| Environmentally Friendly | Yes |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| Physical Characteristics | |
| Weight (Approximate) | 0.25 oz (7 g) |
| Drive Type | Internal |
| Form Factor | M.2 2242 |
| Length | 1.65" (42 mm) |
| Width | 0.87" (22 mm) |
| General Information | |
| Product Type | Solid State Drive |
| Manufacturer Part Number | 901703 |
| Manufacturer Website Address | http://www.visiontek.com |
| Manufacturer | VisionTek Products, LLC |
| Product Name | DLX4 2242 M.2 PCIe 4.0 x4 SSD (NVMe) Opal 2.0 SED |
| Product Series | DLX4 |
| Brand Name | VisionTek |
