Tripp Lite by Eaton QSFP28 to QSFP28 Active Optical Cable - 100GbE, AOC, M/M, Aq

Tripp Lite by Eaton QSFP28 to QSFP28 Active Optical Cable - 100GbE, AOC, M/M, Aq

Regular price $1,211.60 CAD
Regular price $1,357.00 CAD Sale price $1,211.60 CAD
-10% OFF Ask for quote
Shipping calculated at checkout.
Tripp Lite by Eaton QSFP28 to QSFP28 Active Optical Cable - 100GbE, AOC, M/M, Aqua, 10 m (32.8 ft.) - 33 ft (10.06 m) Fiber Optic Network Cable for Switch, Server, Router, Network Device - First End: 1 x QSFP28 Network - Male - Second End: 1 x QSFP28 Network - Male - 100 Gbit/s - 50/125 µm - Aqua

VPN:N28H-10M-AQ SKU:CB261841 CPU:37332225627

  • Features Active
  • Offers a reliable network connectivity
  • Features Fiber Optic cable type

Volume discount available - Ask for quote..

View full details

Recently Viewed

Tripp Lite by Eaton QSFP28 to QSFP28 Active Optical Cable - 100GbE, AOC, M/M, Aq

Product information summary

Tripp Lite by Eaton QSFP28 to QSFP28 Active Optical Cable - 100GbE, AOC, M/M, Aq

About the product

QSFP28 Cable Connects Network Equipment at Speeds up to 100 Gbps

This 10-meter (32.8-foot) QSFP28 Active Optical Cable (AOC) provides next-generation performance by combining four full-duplex 25 Gbps SFP channels into one affordable high-density package. Each male connector contains four independent 850 nm VCSEL-based transmitters and four independent receivers using PIN photo detectors inside. Each lane supports data transfer speeds up to 25 Gbps. Together, the N28H-10M-AQ provides an aggregated speed up to 100 Gbps, making it ideal for switches, servers, routers and other high-end networking equipment.

Push/Pull Tab Connectors Provide Quick, Easy Connections

The hot-pluggable QSFP28 connectors include ergonomic push/pull tabs, which are easily accessible in high-density applications and make the cable easy to install and remove with just one hand.

Engineered and Optimized for Bandwidth-Intense Applications

This QSFP28 active optical cable integrates a 100 Gbps Ethernet-optimized 38-position "board as connector" design. Die-cast zinc connectors offer superior EMI (electromagnetic interference) resistance and reduced crosstalk. The connectors have also been tested to meet stringent insertion loss standards. The cable is suitable for high-speed, short-reach dense data connections, such as 100GBASE-SR4 Ethernet, PCIe, Fibre Channel and InfiniBand applications. The plenum-rated OFNP jacket is designed for connecting network components in drop ceiling, walls and ducts.

Fully Compliant and Compatible with the Latest Standards

This cable is fully compliant with the latest QSFP28 Multi-Source Agreement (MSA), IEEE 802.3bm standards and industry-standard SFF-8636 specifications. It is compatible with all QSFP and QSFP+ ports.

More from the Manufacturer

  • Features Active
  • Offers a reliable network connectivity
  • Features Fiber Optic cable type

Technical Specifications

Miscellaneous
Country of OriginChina
Environmentally FriendlyYes
Physical Characteristics
Shipping Weight (Approximate)5.64 oz (159.98 g)
Shipping Height12" (304.80 mm)
Shipping Width9.10" (231.14 mm)
Product ColorAqua
Color FamilyGreen
General Information
Product TypeNetwork Cable
Manufacturer Part NumberN28H10MAQ
Manufacturer Website Addresshttps://tripplite.eaton.com/
ManufacturerEaton Corporation
Product ModelN28H-10M-AQ
Product NameQSFP28 to QSFP28 Active Optical Cable - 100GbE, AOC, M/M, Aqua, 10 m (32.8 ft.)
Brand NameTripp Lite by Eaton
Technical Information
Cable Length33 ft (10.06 m)
Data Transfer Rate100 Gbit/s
Device SupportedRouter
Switch
Server
Network Device
FeaturesActive
EMI Protection
Cable TypeFiber Optic
Connector Type on First EndQSFP28 Network - Male
Connector Type on Second EndQSFP28 Network - Male
Fiber Optic ModeMulti-mode
Connector on First End Details1 x QSFP28 Network - Male
Connector on Second End Details1 x QSFP28 Network - Male
Fiber Optic Cable Core/Cladding Specification50/125 µm
