About the product
The Eaton® 9E UPS delivers superior power protection for everexpanding loads in today's space-constrained data centers. Facilitating a lower total cost of ownership (TCO) through three key features - energy-efficiency, internal batteries and compact footprint - the 9E is an ideal solution for small- to mediumsized data centers and other applications desiring highly reliable power protection.
Energy-efficient performance lowers operating costs
- Delivers up to 98% efficiency
- Up to 7% more efficient than competitive units
- Qualifies for local utility rebates and incentives
Internal batteries provide maximum runtime
- Delivers up to 21 minutes of runtime
- Pre-wired for easy installation
Compact footprint occupies minimal floor space
- Up to 35% smaller than similar competitive solutions
- Allows dedication of more floor space to revenueproducing equipment
Technical Specifications
| Controls/Indicators | |
| Status Indicators | 4 x LEDs For Notice and Alarm |
| Display & Graphics | |
| Display | LCD |
| Management | |
| Network Management | RS-232 |
| Environmental Conditions | |
| Maximum Operating Temperature | 86°F (30°C) |
| Sound Emission (A-Weighted) | 64 dB(A) |
| Interfaces/Ports | |
| Serial Port | Yes |
| EPO Port | Yes |
| Battery Information | |
| Battery Chemistry | Lead Acid |
| Battery Capacity | 9000 mAh |
| Backup/Run Time (Full Load) | 5 Minute |
| Battery Characteristics | Maintenance-free/Sealed |
| Replaceable Battery | Yes |
| Physical Characteristics | |
| Weight (Approximate) | 1499.14 lb (680000 g) |
| Form Factor | Tower |
| Height | 74.02" (1880 mm) |
| Width | 23.62" (600 mm) |
| Depth | 31.50" (800 mm) |
| Product Color | Black |
| Power Description | |
| Input Voltage | 230 V AC |
| Output Voltage | 220 V AC |
| 208 V AC | |
| Input Frequency | 72 Hz |
| Load Capacity (VA) | 60 kVA |
| Load Capacity (Watt) | 48 kW |
| General Information | |
| Product Type | Double Conversion Online UPS |
| Manufacturer Part Number | 9EB06GG05002003 |
| Manufacturer Website Address | http://www.eaton.com/EatonCom/Markets/NorthAmerica |
| Packaged Quantity | 1 Pack |
| Manufacturer | Eaton Corporation |
| Product Name | 9E 60kVA Tower UPS |
| Product Series | 9E |
| Brand Name | Eaton |
| Technical Information | |
| Application/Usage | Education |
| Telecommunication | |
| IT | |
| Industrial | |
| Healthcare | |
| Banking | |
| Corporate | |
| Data Center | |
| Government | |
| Overload Protection | Yes |
| Plug/Connector Type | Hard Wire 4-wire |
| Receptacle Type | Hardwired |
| Transfer Time | 20 ms |
| Receptacle Detail | 1 x Hardwired |
