About the product
Smart-UPS provides availability and manageability to your network allowing you to focus on business growth instead of business downtime. Trusted to protect critical data and equipment from power problems by supplying clean and reliable network-grade power.
Connected Smart-UPS units utilize a unique networking feature that makes Smart-UPS even more adaptable and easier to deploy: APC SmartConnect. It allows you to view the status of your UPS through a secure web portal. Through this innovative remote monitoring interface, you'll receive automatic notifications, firmware updates, and advanced support.
Designed by APC™ by Schneider Electric™, the Smart-UPS™ is the most popular UPS in the world for servers, storage and network power protection.
- 1500 VA / 1000 W battery backup uninterruptible power supply (UPS)
- View the status of your UPS on a secure portal via any Internet-connected device, receive notifications, firmware updates and more
- 6 total battery backup and surge protected outlets
- Pure sine wave output while on battery provides a high degree of compatibility for active PFC servers and sensitive electronics
- Automatic voltage regulation (AVR) adjusts high and low voltages to a safe level
- Works adequately in situations where the supply is prone to sags and surges
- 1.50 kVA load capacity - work without any interruption during power outages
- 1 kW load capacity - backup power for your valuable electronics
- Up to 7.20 minute runtime on full load to preserve critical data from power shortage interruptions
Technical Specifications
| Display & Graphics | |
| Display | LCD |
| Warranty | |
| Additional Warranty Information | Equipment Protection Value 150000 US Dollars Limited warranty - batteries - 2 years |
| Management | |
| Network Management | SmartConnect |
| RS-232 | |
| Environmental Conditions | |
| Minimum Operating Temperature | 32°F (0°C) |
| Maximum Operating Temperature | 104°F (40°C) |
| Sound Emission (A-Weighted) | 45 dB(A) |
| Battery Information | |
| Battery Chemistry | Lead Acid |
| Backup/Run Time (Full Load) | 7.20 Minute |
| Battery Characteristics | Maintenance-free, Sealed, Leak-proof |
| Typical Battery Recharge Time | 3 Hour |
| Miscellaneous | |
| Package Contents |
|
| Certifications & Standards |
|
| Energy Star | Yes |
| Environmental Compliance | Registration, Evaluation, Authorization and Restriction of Chemicals (REACH) |
| Restriction of Hazardous Substances (RoHS) | |
| Interfaces/Ports | |
| USB | Yes |
| Network (RJ-45) | Yes |
| Number of USB Ports | 1 |
| Serial Port | Yes |
| Expansion Slot Detail | 1 x (total) / 0 (free) x SmartSlot |
| Interfaces Detail |
|
| General Information | |
| Product Type | Line-interactive UPS |
| Manufacturer Part Number | AA839559 |
| Manufacturer Website Address | http://www1.ca.dell.com |
| Manufacturer | Dell Technologies |
| Product Name | Smart-UPS 1500VA Rack-mountable UPS |
| Product Line | Smart-UPS |
| Brand Name | Dell |
| Physical Characteristics | |
| Weight (Approximate) | 26.50 kg |
| Form Factor | Rack-mountable |
| Rack Height | 2U |
| Height | 0.34" (8.60 mm) |
| Width | 1.70" (43.20 mm) |
| Depth | 1.88" (47.80 mm) |
| Product Color | Black |
| Color Family | Black |
| Technical Information | |
| Application/Usage | Storage |
| Network | |
| Server | |
| Equipment | |
| Features | Audible Alarm |
| Plug/Connector Type | NEMA 5-15P |
| Cord Length | 8 ft |
| Receptacle Type | NEMA 5-15R |
| AVR | Yes |
| Number of Battery & Surge Outlets | 6 |
| Receptacle Detail | 6 x NEMA 5-15R |
| Power Description | |
| Circuit Breaker | Yes |
| Input Voltage | 120 V AC |
| Output Voltage | 120 V AC |
| Surge Energy Rating | 680 J |
| Waveform Type | Pure Sine Wave |
| Input Voltage Range | 82 V AC - 144 V AC |
| 75 V AC - 154 V AC | |
| Output Frequency | 50 Hz |
| 60 Hz | |
| Input Frequency | 60 Hz |
| 50 Hz | |
| Load Capacity (VA) | 1.50 kVA |
| Load Capacity (Watt) | 1 kW |
