About the product
The compact, Ethernet only environmentally-hardened ACX2200 router with fanless passive cooling has a fixed port configuration that includes four copper 10/100/1000Mbps interfaces, four combination copper/fiber GbE ports, two GbE SFP ports, and two 10 GbE SFP+ ports.
A built-in service engine makes the ACX2200 fully customizable and future-proof for LTE-A and 5G requirements. The scalability and reliability of the ACX2200 improves customer satisfaction, while lowering the total cost of operating, maintaining, and updating the network infrastructure for service providers and enterprises.
- Built-in power supply to ensure all components are being supplied with accurate voltage
- Optimize the performance of business networks with the 10 Gigabit Ethernet connectivity
- Management capability provides control over the router's setup and configuration
- Features management port for a reliable networking
- With 1000Base-X technology, get up to 1000 mbps data transfer rate over supported network cable
Technical Specifications
| Miscellaneous | |
| Certifications & Standards | Safety:
|
| Environmentally Friendly | Yes |
| I/O Expansions | |
| Expansion Slot Type | SFP |
| SFP+ | |
| Total Number of Expansion Slots | 8 |
| Network & Communication | |
| Network Technology | 1000Base-X |
| 10GBase-X | |
| 10/100/1000Base-T | |
| Ethernet Technology | 10 Gigabit Ethernet |
| Power Description | |
| Input Voltage | 120 V AC |
| 230 V AC | |
| Power Source | Power Supply |
| PoE (RJ-45) Port | No |
| Redundant Power Supply Supported | Yes |
| Physical Characteristics | |
| Weight (Approximate) | 8.30 lb (3764.82 g) |
| Form Factor | Rack-mountable |
| Height | 1.75" (44.45 mm) |
| Width | 17.50" (444.50 mm) |
| Depth | 9.40" (238.76 mm) |
| Compatible Rack Unit | 1U |
| Interfaces/Ports | |
| Token Ring Port | No |
| USB | Yes |
| Number of Network (RJ-45) Ports | 8 |
| Powerline | No |
| Management Port | Yes |
| Total Number of Ports | 8 |
| Serial V.35 Interface | No |
| General Information | |
| Product Type | Router |
| Manufacturer Part Number | ACX2200-AC |
| Manufacturer Website Address | http://www.juniper.net |
| Manufacturer | Juniper Networks, Inc |
| Product Model | ACX2200 |
| Product Name | ACX2200 Router |
| Product Series | ACX |
| Brand Name | Juniper |
