About the product
This is a mini media converter that converts a 10/100/1000Base-TX(RJ-45) to 1000Base-SX via a 850nm multi-mode fiber (MMF) SC connector, which allows distance reach up to 550m. This provides a cost effective conversion from 10/100/1000Base-TX(RJ-45) to 1000Base-SX fiber, while extending the network reach beyond the 100m reach limitation of copper and saving space (3.75" x 2.25" x 1"). Our media converters are 100% compliant for all of our networking needs. Now you have a cost effective solution to your network upgrade needs.
- Expand your network capacity and fulfill requirement with this 2 transceiver/media converter
- With 10/100/1000Base-TX technology get up to 1000Mbps data transfer rate over twisted pair cable
- Supports twisted pair cables for durability and improved signal transfer while ensuring smooth and seamless data transfer
Technical Specifications
| Power Description | |
| Power Source | Power Adapter |
| Miscellaneous | |
| Application/Usage | Network |
| TAA Compliant | No |
| Network & Communication | |
| Network Technology | 10/100/1000Base-TX |
| 1000Base-SX | |
| Ethernet Technology | Gigabit Ethernet |
| Physical Characteristics | |
| Weight (Approximate) | 1 lb (453.59 g) |
| Height | 5.60" (142.24 mm) |
| Width | 3" (76.20 mm) |
| Depth | 2.50" (63.50 mm) |
| Media & Performance | |
| Maximum Distance Supported | 0.55 km (0.34 Mile) |
| Media Type Supported | Optical Fiber |
| Twisted Pair | |
| Fiber Mode Supported | Multi-mode |
| Fiber Optic Cable Wavelength | 0.03 mil (0 mm) |
| General Information | |
| Product Type | Transceiver/Media Converter |
| Manufacturer Part Number | ADD-GMCMN-SX-SC |
| Manufacturer Website Address | http://www.addoncomputer.com |
| Packaged Quantity | 1 |
| Manufacturer | AddOn |
| Product Name | 10/100/1000Base-TX(RJ-45) to 1000Base-SX(SC) MMF 850nm 550m Mini Media Converter |
| Brand Name | AddOn |
| Interfaces/Ports | |
| USB | No |
| DVI | No |
| Number of Network (RJ-45) Ports | 1 |
| Network (RJ-45) | Yes |
| Management Port | No |
| Number of SC Ports | 1 |
| Total Number of Ports | 2 |
