About the product
This is a media converter card that converts a 10/100/1000Base-TX(RJ-45) to SFP. The open SFP port allows users to customize between the SX, LX, CWDM, bidirectional, or etc. connections. This media converter provides a cost effective conversion from 10/100/1000Base-TX(RJ-45) to SFP, while extending the network reach beyond the 100m reach limitation of copper. This device can be managed if used in our managed rack system or unmanaged with our unmanaged rack system or standalone chassis enclosure. Our media converters and network interface cards are 100% compliant for all of our networking needs. Now you have a cost effective solution to your network upgrade needs.
- Attach multiple devices together or expand the number of devices connected to your existing network by using 2 transceiver/media converter
- With 10/100/1000Base-T technology get up to 1000Mbps data transfer rate over twisted pair cable
- The Internal provides convenient installation
- Supports optical fiber cable for durable performance, minimal signal loss, and fast data transfers to greater distances
Technical Specifications
| I/O Expansions | |
| Expansion Slot Type | SFP |
| Number of SFP Slots | 1 |
| Total Number of Expansion Slots | 1 |
| Interfaces/Ports | |
| Number of Network (RJ-45) Ports | 1 |
| Network (RJ-45) | Yes |
| Total Number of Ports | 2 |
| Network & Communication | |
| Network Technology | 1000Base-X |
| 10/100/1000Base-T | |
| Ethernet Technology | Gigabit Ethernet |
| Media & Performance | |
| Media Type Supported | Twisted Pair |
| Optical Fiber | |
| Fiber Mode Supported | Single-mode |
| Multi-mode | |
| Miscellaneous | |
| Additional Information | For Rack or Standalone Systems |
| Application/Usage | Network |
| Compatibility | ADD-RACK-16 Media Converter Chassis |
| Environmentally Friendly | Yes |
| TAA Compliant | No |
| Physical Characteristics | |
| Weight (Approximate) | 3.20 oz (90.72 g) |
| Form Factor | Internal |
| Height | 1" (25.40 mm) |
| Width | 3.50" (88.90 mm) |
| Depth | 4.50" (114.30 mm) |
| General Information | |
| Product Type | Transceiver/Media Converter |
| Manufacturer Part Number | ADD-MCCTXSFP |
| Manufacturer Website Address | http://www.addoncomputer.com |
| Packaged Quantity | 1 |
| Manufacturer | AddOn |
| Product Model | ADD-MCCTXSFP |
| Product Name | 1000Base-TX with Open SFP Slot Media Converter Card |
| Brand Name | AddOn |
