Supermicro A+ Server AS -2024S-TR Server Barebone System - 2U Rack-mou

Name: Supermicro A+ Server AS -2024S-TR Server Barebone System - 2U Rack-mou
Brand: Super Micro
SKU: RSC192873
Price: 8854.43 CAD
Availability: OutOfStock

$8,854.43 CAD

~~$9,916.96 CAD~~ $8,854.43 CAD

-10% OFF Ask for quote

Shipping calculated at checkout.

Supermicro A+ Server AS -2024S-TR Server Barebone System - 2U Rack-mountable - Socket SP3 - 2 x Processor Support - AMD Chip - 4 TB DDR4 SDRAM DDR4-3200/PC4-25600 Maximum RAM Support - 16 Total Memory Slots - Serial ATA/600, NVMe, 12Gb/s SAS Controller - 12 3.5\" Bay(s) - Network (RJ-45) - 1 M.2 Interface(s) - Processor Support (EPYC) - Gigabit Ethernet - 2 USB 3.0 Port(s) - 2 x 920 W - 3 Year

VPN:AS -4124GS-TNR SKU:RSC192873 UPC:

Connect USB-enabled devices via 2 USB ports
DDR4 SDRAM compatible slot - Install memory that synchronizes electrical and clock signals for an efficient data throughput
12Gb/s SAS interface for high speed and reliability

Quantity

Volume discount available - Ask for quote..

View full details

Product information summary

Supermicro A+ Server AS -2024S-TR Server Barebone System - 2U Rack-mou

About the product

2U Dual Processor Rackmount Servers

? Flexible Solution for High-Demand Workloads

Connect USB-enabled devices via 2 USB ports
DDR4 SDRAM compatible slot - Install memory that synchronizes electrical and clock signals for an efficient data throughput
12Gb/s SAS interface for high speed and reliability
Up to 10x faster than standard Ethernet connectivity and provides high-performance uplinks
Compatible EPYC processor lets you perform all your computational tasks at a swift pace

Technical Specifications

Chipset
Chipset Manufacturer	AMD
Miscellaneous
Package Contents	1 x Super H12DSi-N6 Motherboard 1 x 2U Chassis 1 x 2U 12-Slot LFF Backplane Supports 12 x SAS3/SATA3/NVMe4 Storage Devices with 1x(2x4) + 4x(1x4) power connectors, co-lay with BPN-SAS3-LA26A-N12,HF,RoHS 2 x PWCD,US,NEMA5-15P TO IEC60320 C13,6FT,16AWG,RoHS/REACH 2 x SlimSAS x4 (STR) to 4x SATA,65CM,100 OHM,RoHS 2 x Slimline x8 (STR) to Slimline x8 (STR),45CM,85 OHM,RoHS 1 x ROUND 16 TO 16 PIN RIBBON FP CABLE 30"L, LF 1 x STD I/O shield for X9 socket R server MB with Gasket. 1 x Rail set, quick/quick, default for 2,3U 17.2"W 1 x SC825/826/216/213 Intel DP X9,X8 air shroud 13.68x13/12x13 1 x Screw bag and NVMe HDD label for 12x 3.5" Gen-9 HDD Tray 12 x Black gen-9 tool-less cost-effective 3.5 1 x AS -2024S-TR Quick Reference Guide 1 x License key for enabling OOB BIOS management 2 x 2U Passive CPU Heat Sink for AMD Socket SP3 Processors 2 x 1U, platinum efficiency,920W,AC input:100-127/200-240Vac,HF, 1 x 2U cost effective PDB support up to 1200W.,RoHS 3 x 80x80x38 mm, 9.4K RPM, Hot-swappable Middle Cooling Fan for X11 Purley Platform Newly Enabled 2U+ Chassis 1 x 216B/826B LP rear window,RoHS/REACH,PBF
Network & Communication
Ethernet Technology	Gigabit Ethernet
Controllers
Controller Type	Serial ATA/600
	NVMe
	12Gb/s SAS
Interfaces/Ports
Network (RJ-45)	Yes
Total Number of USB Ports	2
Number of USB 3.0 Ports	2
Number of VGA Ports	1
Memory
Maximum Memory Supported	4 TB
Memory Technology	DDR4 SDRAM
Memory Standard	DDR4-3200/PC4-25600
Total Number of Memory Slots	16
Processor
Processor Supported	EPYC
Processor Socket	Socket SP3
64-bit Processing	Yes
Number of Processors Supported	2
Power Description
Input Voltage	230 V AC
	120 V AC
Plug/Connector Type	NEMA 5-15P to C13
Number of Power Supplies Installed	2
Maximum Power Supply Wattage	920 W
Storage
Supported Storage Drive Interfaces	PCI Express
	SAS-3
	Serial ATA III
Supported Storage Drive Types	SSD
	HDD
I/O Expansions
Number of Total Expansion Bays	12
"Number of 3.5"" Bays"	12
Number of PCI Express x8 Slots	3
Number of PCI Express x16 Slots	3
Total Number of Expansion Slots	6
Number of M.2 Interfaces	1
General Information
Product Type	Server Barebone System
Manufacturer Part Number	AS4124GSTNR
Manufacturer Website Address	http://www.supermicro.com
Manufacturer	Supermicro Computer, Inc
Product Model	AS -2024S-TR
Product Name	A+ Server AS -2024S-TR
Product Line	A+ Server
Brand Name	Supermicro
Physical Characteristics
Weight (Approximate)	33.50 lb (15195.34 g)
Form Factor	Rack-mountable
Rack Height	2U
Height	3.50" (88.90 mm)
Width	17.20" (436.88 mm)
Depth	25.50" (647.70 mm)
Product Color	Silver
Color Family	Silver
