About the product
Cisco® ASR 920 Series Aggregation Services Routers are full-featured converged access platforms designed for the cost-effective delivery of wireline and wireless services. They are temperature hardened, high-throughput, small form factor, low-power-consumption routers optimized for mobile backhaul, residential, and business service applications. The Cisco ASR 920 Router provides a comprehensive and scalable feature set of Layer 2 VPN (L2VPN) and Layer 3 VPN (L3VPN) services in a compact package. It also enables service providers to deploy Multiprotocol Label Switching (MPLS)-based VPN services from within the access layer. Designed around key Carrier Ethernet features that simplify network operation, the Cisco ASR 920 Series enables premium services with enhanced service-level agreement (SLA) capabilities. An optional "pay-as-you-grow" feature and service activation model gives service providers a flexible, cost-effective solution.
- Create a wired network with all the PCs connected with this router and share your Internet connection as well as files while checking emails
- Built-in power supply to ensure all components are being supplied with accurate voltage
- Rack-mountable feature for convenient and safe installation of the router
- Optimize the performance of business networks with the 10 Gigabit Ethernet connectivity
- With 10/100/1000Base-T technology, get up to 1000 mbps data transfer rate over twisted pair cable
Technical Specifications
| Management & Protocols | |
| Security Features |
|
| Miscellaneous | |
| Country of Origin | Thailand |
| I/O Expansions | |
| Expansion Slot Type | SFP+ |
| SFP | |
| Total Number of Expansion Slots | 14 |
| Memory | |
| Flash Memory | 2 GB |
| Standard Memory | 4 GB |
| Memory Technology | DRAM |
| Network & Communication | |
| Network Technology | 1000Base-X |
| 10GBase-X | |
| 10/100/1000Base-T | |
| Ethernet Technology | 10 Gigabit Ethernet |
| Power Description | |
| Input Voltage | 120 V AC |
| 230 V AC | |
| Power Source | Power Supply |
| PoE (RJ-45) Port | No |
| Redundant Power Supply Supported | Yes |
| Interfaces/Ports | |
| Token Ring Port | No |
| USB | Yes |
| Number of Network (RJ-45) Ports | 8 |
| Powerline | No |
| Management Port | Yes |
| Total Number of Ports | 8 |
| Serial V.35 Interface | No |
| Physical Characteristics | |
| Weight (Approximate) | 8.60 lb (3900.89 g) |
| Form Factor | Rack-mountable |
| Desktop | |
| Height | 1.70" (43.18 mm) |
| Width | 17.50" (444.50 mm) |
| Depth | 9.10" (231.14 mm) |
| Compatible Rack Unit | 1U |
| General Information | |
| Product Type | Router |
| Manufacturer Part Number | ASR-920-12CZ-A |
| Manufacturer Website Address | http://www.cisco.com |
| Manufacturer | Cisco Systems, Inc |
| Product Model | ASR-920-12CZ-A |
| Product Name | ASR-920-12CZ-A Router |
| Product Series | ASR 920 |
| Brand Name | Cisco |
