About the product
Overview | Full size Z tower power at half the size
Get all the power of a full size tower at a fraction of the size. Re-engineered to fit full-height, full-length graphics while leaving room for upgrades and expansion, the Z2 SFF delivers high performance for your intensive workflow-from 3D design to real time ray tracing-now and in the future.
Full height, full length performance
Design, simulate and real time ray trace on a Z SFF -- FHFL pro graphics and Intel® Core™ processors.
ISV Certified
Work with confidence knowing your PC is certified with leading software applications to ensure peak performance.
Configurable for today. Expandable for tomorrow.
Accelerate your current workflow with options across processor, graphics, memory, storage, and I/O ports.
Features | Windows 11
Work anywhere without compromising on performance or security with Windows 11 powered by HP's collaboration and connectivity technology.
Intel® Core™ i9 processor
Get high-end performance for intensive tasks like rendering and video editing with the Intel® Core™ i9 processor.
Smaller, Functional Design
The stunning new design features front and rear ledges, so you can easily move your system from location to location.
Tool-less Access
Evolve your work. Evolve your rig. With a tool-less sliding access cover, you can easily get into the the interior, and customize your Z to fit your needs.
Thermal Management
Innovatively designed to keep hardware components cool and quiet no matter how hard you push it. Have confidence to run your system at max load 24/7.
Custom Performance Modes
Take on the toughest workflows with three custom pre-set modes that optimize performance from the BIOS-High Performance, Performance and Quiet.
- Up to 10x faster than standard Ethernet connectivity and provides high-performance uplinks
- 550 W power supply unit (PSU) included
- With 64 GB of memory, run as many programs as you want without losing the execution performance
- 12 TB HDD provides you with gigantic space for all your files, document and digital content
Technical Specifications
| Network & Communication | |
| Ethernet Technology | Gigabit Ethernet |
| Warranty | |
| Additional Warranty Information | |
| Chipset | |
| Chipset Manufacturer | Intel |
| Chipset Model | W680 |
| Operating System | |
| Operating System | Windows 11 Pro |
| Operating System Platform | Windows |
| Display & Graphics | |
| Graphics Controller Model | RTX A4000 |
| Graphics Memory Capacity | 16 GB |
| Graphics Memory Accessibility | Dedicated |
| Controllers | |
| RAID Levels | 0, 1 |
| Controller Type | Serial ATA/600 |
| NVMe | |
| RAID Supported | Yes |
| Power Description | |
| Input Voltage | 120 V AC |
| 230 V AC | |
| Frequency | 60 Hz |
| 50 Hz | |
| Maximum Power Supply Wattage | 550 W |
| Storage | |
| Drive Type | HDD/SSD |
| Hard Drive Interface | Serial ATA/600 |
| Solid State Drive Interface | PCI Express NVMe 4.0 x4 |
| Total Hard Drive Capacity | 12 TB |
| Total Solid State Drive Capacity | 1 TB |
| General Information | |
| Product Type | Workstation |
| Manufacturer Part Number | AY5B0UA#ABA |
| Manufacturer Website Address | http://www.hp.com |
| Manufacturer | HP Inc. |
| Product Name | Z2 Small Form Factor G9 Workstation |
| Product Series | Z2 G9 |
| Brand Name | HP |
| Physical Characteristics | |
| Weight (Approximate) | 11.02 lb (5000 g) |
| Form Factor | Small Form Factor |
| Height | 3.94" (100 mm) |
| Width | 15.12" (384 mm) |
| Depth | 12.13" (308 mm) |
| Product Color | Black |
| Color Family | Black |
| Memory | |
| Error Checking | Non-ECC |
| Maximum Memory Supported | 128 GB |
| Signal Processing | Unbuffered |
| Standard Memory | 64 GB |
| Memory Technology | DDR5 SDRAM |
| Memory Clock Speed | 4.80 GHz |
| Memory Configuration | 2 x 32GB |
| Total Number of Memory Slots | 4 |
| Interfaces/Ports | |
| HDMI | Yes |
| DisplayPort | Yes |
| Number of DisplayPort Outputs | 2 |
| Number of HDMI Outputs | 1 |
| Total Number of USB Ports | 12 |
| Number Of Ethernet Ports | 1 |
| USB Type-C | Yes |
| USB Type-C Detail | 1 Type-C SuperSpeed USB 20Gbps signaling rate port (charge supports up to 5V/3A) |
| Optional Ports | Details regarding optional ports aggregated from the information available for this product's family/series. Flex IO - choose one of the following options:
Front
Rear
|
| Miscellaneous | |
| Package Contents |
|
| Environmentally Friendly | Yes |
| Environmental Certification | China Environmental United Certification Center (CEC) |
| Energy Star | Yes |
| TCO Certified | Yes |
| Energy Efficiency Certification | China Energy Conservation Program (CECP) |
| Energy Efficiency Compliance | Energy-related Products Directive (ErP) |
| Environmental Compliance | Waste Electrical and Electronic Equipment Directive (WEEE) |
| Restriction of Hazardous Substances (RoHS) | |
| Processor | |
| Processor Speed | 2 GHz |
| Processor Type | Core i9 |
| Processor Socket | Socket LGA-1700 |
| L3 Cache | 36 MB |
| Processor Model | i9-14900 |
| Processor Core | Tetracosa-core (24 Core) |
| Number of Processors Supported | 1 |
| Number of Processors Installed | 1 |
| vPro Technology | Yes |
| Processor Generation | 14th Gen |
| Processor Threads | 32 |
