About the product
Full size Z tower power at half the size
Get all the power of a full size tower at a fraction of the size. Re-engineered to fit full-height, full-length graphics while leaving room for upgrades and expansion, the Z2 SFF delivers high performance for your intensive workflow-from 3D design to real time ray tracing-now and in the future.
Full height, full length performance
Design, simulate and real time ray trace on a Z SFF -- FHFL pro graphics and Intel® Core™ processors.
ISV Certified
Work with confidence knowing your PC is certified with leading software applications to ensure peak performance.
Configurable for today. Expandable for tomorrow.
Accelerate your current workflow with options across processor, graphics, memory, storage, and I/O ports.
Featuring | Windows 11
Work anywhere without compromising on performance or security with Windows 11 powered by HP's collaboration and connectivity technology.
Intel® Core™ i7 processor
Run several CPU-heavy programs simultaneously without sacrificing performance with an Intel® Core™ i7 processor.
Security is your top priority
The HP Wolf Pro Security Edition provides precon?gured enterprise-level PC protection for small and medium sized businesses.
Smaller, Functional Design
The stunning new design features front and rear ledges, so you can easily move your system from location to location.
Tool-less Access
Evolve your work. Evolve your rig. With a tool-less sliding access cover, you can easily get into the the interior, and customize your Z to fit your needs.
Thermal Management
Innovatively designed to keep hardware components cool and quiet no matter how hard you push it. Have confidence to run your system at max load 24/7.
- Up to 10x faster than standard Ethernet connectivity and provides high-performance uplinks
- 450 W power supply unit (PSU) included
- Intel Core i7 2.10 GHz processor offers lightning fast speed and peak performance even for the toughest tasks and processing intensive games
- 16 GB of gigantic memory enables you to do multitasking and run intensive games lag-free
Technical Specifications
| Input Devices | |
| Keyboard Localization | English |
| Network & Communication | |
| Ethernet Technology | Gigabit Ethernet |
| Chipset | |
| Chipset Manufacturer | Intel |
| Chipset Model | W680 |
| Display & Graphics | |
| Graphics Controller Model | RTX A400 |
| Graphics Memory Capacity | 4 GB |
| Graphics Memory Accessibility | Dedicated |
| Operating System | |
| Operating System | Windows 11 Pro |
| Operating System Platform | Windows |
| Operating System Language | English |
| Storage | |
| Drive Type | SSD |
| Solid State Drive Interface | PCI Express NVMe |
| Total Solid State Drive Capacity | 512 GB |
| Controllers | |
| RAID Levels | 0, 1 |
| Controller Type | Serial ATA/600 |
| NVMe | |
| RAID Supported | Yes |
| Power Description | |
| Input Voltage | 120 V AC |
| 230 V AC | |
| Frequency | 50 Hz |
| 60 Hz | |
| Maximum Power Supply Wattage | 450 W |
| General Information | |
| Product Type | Workstation |
| Manufacturer Part Number | B29Y6UT#ABA |
| Manufacturer Website Address | http://www.hp.com |
| Manufacturer | HP Inc. |
| Product Name | Z2 Small Form Factor G9 Workstation |
| Product Series | Z2 G9 |
| Brand Name | HP |
| Interfaces/Ports | |
| DisplayPort | Yes |
| Number of DisplayPort Outputs | 2 |
| Total Number of USB Ports | 12 |
| Number Of Ethernet Ports | 1 |
| USB Type-C | Yes |
| USB Type-C Detail | 1 x SuperSpeed USB Type-C® 20Gbps signaling rate (USB Power Delivery, DisplayPort™ 1.4, HP Sleep and Charge |
| Optional Ports | Details regarding optional ports aggregated from the information available for this product's family/series. Flex I/O module: choose one from the following:
|
| Memory | |
| Error Checking | Non-ECC |
| Maximum Memory Supported | 128 GB |
| Signal Processing | Unbuffered |
| Standard Memory | 16 GB |
| Memory Technology | DDR5 SDRAM |
| Memory Configuration | 1 x 16GB |
| Total Number of Memory Slots | 4 |
| Miscellaneous | |
| Package Contents |
|
| Energy Star | Yes |
| TCO Certified | Yes |
| Energy Efficiency Certification | China Energy Conservation Program (CECP) |
| Energy Efficiency Compliance | Energy-related Products Directive (ErP) |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| Waste Electrical and Electronic Equipment Directive (WEEE) | |
| Physical Characteristics | |
| Weight (Approximate) | 11.02 lb (5000 g) |
| Form Factor | Small Form Factor |
| Height | 3.94" (100 mm) |
| Width | 15.12" (384 mm) |
| Depth | 12.13" (308 mm) |
| Product Color | Black |
| Color Family | Black |
| Processor | |
| Processor Speed | 2.10 GHz |
| Processor Type | Core i7 |
| Processor Socket | Socket LGA-1700 |
| L3 Cache | 33 MB |
| Processor Model | i7-14700 |
| Processor Core | Icosa-core (20 Core) |
| Number of Processors Supported | 1 |
| Number of Processors Installed | 1 |
| Processor Generation | 14th Gen |
| Processor Threads | 28 |
