About the product
Powers large workflows. Fits a tiny space.
Tackle workflows you never thought before possible on such a tiny PC. The HP Z2 Mini easily fits on your desk or behind your monitor so you can tackle 3D projects without losing valuable office space. All while feeling protected From the BIOS to the browser, above, in, and below the OS with HP Wolf Security Suite.
Unprecedented Z mini power
Get a standard low-profile NVIDIA® GPU and an Intel© CPU for seamless design, rendering and simulation.
Engineered to Evolve with your worflow
The new slide-out design gives tool-free interior access so you can easily swap graphics, memory, and more.
Fits anywhere
Create your ideal workspace in an office or at home. Mount the Z2 mini behind your monitor or under your desk.
Industry leading security. Reliability you can trust
Get peace of mind with a PC that's built to endure. The Z2 Mini undergoes 360K hours of rigorous testing, military-standard testing and is certified for pro apps. And with HP Wolf Security for Business, it's protected below, in and above the OS.
Features | Windows 11
Work anywhere without compromising on performance or security with Windows 11 powered by HP's collaboration and connectivity technology.
Intel® Core™ i5 processor
Experience powerful performance and seamless computing for your everyday tasks and higher performance needs with the Intel® Core™ i5 processor.
Multi-Display Support
See all your windows in perfect detail with support for up to 8 displays at 4K resolution
Tool-less Access
Evolve your work. Evolve your rig. With a tool-less sliding access cover, you can easily get into the the interior, and customize your Z to fit your needs.
Network Connectivity
Connect and collaborate quickly with 10Gb Ethernet interface.
Thermal Management
Innovatively designed to keep hardware components cool and quiet no matter how hard you push it. Have confidence to run your system at max load 24/7.
- Optimize the performance of business networks with 10 Gigabit Ethernet connectivity
- 280 W power supply unit (PSU) fulfills your system's power requirements
- Intel Core i5 2.70 GHz processor provides you with a solid performance to watch videos, play games, and at the same time, its adaptability makes you more productive
- 16 GB of gigantic memory enables you to do multitasking and run intensive games lag-free
Technical Specifications
| Network & Communication | |
| Ethernet Technology | 10 Gigabit Ethernet |
| Warranty | |
| Additional Warranty Information | |
| Chipset | |
| Chipset Manufacturer | Intel |
| Chipset Model | W680 |
| Display & Graphics | |
| Graphics Controller Model | UHD Graphics 770 |
| Graphics Memory Accessibility | Shared |
| Operating System | |
| Operating System | Windows 11 Pro |
| Operating System Platform | Windows |
| Controllers | |
| RAID Levels | 0, 1 |
| Controller Type | NVMe |
| RAID Supported | Yes |
| Storage | |
| Drive Type | SSD |
| Solid State Drive Interface | PCI Express NVMe |
| Total Solid State Drive Capacity | 256 GB |
| Power Description | |
| Input Voltage | 120 V AC |
| 230 V AC | |
| Frequency | 60 Hz |
| 50 Hz | |
| Maximum Power Supply Wattage | 280 W |
| Memory | |
| Error Checking | Non-ECC |
| Maximum Memory Supported | 64 GB |
| Standard Memory | 16 GB |
| Memory Technology | DDR5 SDRAM |
| Memory Configuration | 2 x 8GB |
| Total Number of Memory Slots | 2 |
| Physical Characteristics | |
| Weight (Approximate) | 5.29 lb (2400 g) |
| Form Factor | Mini PC |
| Cooler Type | Air Cooler |
| Height | 2.72" (69 mm) |
| Width | 8.31" (211 mm) |
| Depth | 8.58" (218 mm) |
| General Information | |
| Product Type | Workstation |
| Manufacturer Part Number | B41KGUA#ABA |
| Manufacturer Website Address | http://www.hp.com |
| Manufacturer | HP Inc. |
| Product Name | Z2 Mini G9 Workstation |
| Product Series | Z2 Mini G9 |
| Brand Name | HP |
| Interfaces/Ports | |
| DisplayPort | Yes |
| Number of DisplayPort Outputs | 2 |
| Total Number of USB Ports | 6 |
| Number Of Ethernet Ports | 1 |
| USB Type-C | Yes |
| USB Type-C Detail | 2 x SuperSpeed USB Type-C 20Gbps signaling rate |
| Optional Ports | Details regarding optional ports aggregated from the information available for this product's family/series. Flex IO, choice of:
|
| Miscellaneous | |
| Package Contents |
|
| Environmentally Friendly | Yes |
| Environmental Certification | Electronic Product Environmental Assessment Tool Gold (EPEAT Gold) |
| Electronic Product Environmental Assessment Tool Climate+ (EPEAT Climate+) | |
| Energy Star | Yes |
| TCO Certified | Yes |
| Energy Efficiency Certification | China Energy Conservation Program (CECP) |
| Energy Efficiency Compliance | Energy-related Products Directive (ErP) |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| Waste Electrical and Electronic Equipment Directive (WEEE) | |
| Processor | |
| Processor Speed | 2.70 GHz |
| Processor Type | Core i5 |
| Processor Socket | Socket LGA-1700 |
| L3 Cache | 24 MB |
| Processor Model | i5-14600 |
| Processor Core | Tetradeca-core (14 Core) |
| Number of Processors Supported | 1 |
| Number of Processors Installed | 1 |
| Processor Generation | 14th Gen |
| Processor Threads | 20 |
