About the product
Powers large workflows. Fits a tiny space.
Tackle workflows you never thought before possible on such a tiny PC. The HP Z2 Mini easily fits on your desk or behind your monitor so you can tackle 3D projects without losing valuable office space. All while feeling protected From the BIOS to the browser, above, in, and below the OS with HP Wolf Security Suite.
Unprecedented Z mini power
Get a standard low-profile NVIDIA® GPU and an Intel© CPU for seamless design, rendering and simulation.
Engineered to Evolve with your worflow
The new slide-out design gives tool-free interior access so you can easily swap graphics, memory, and more.
Fits anywhere
Create your ideal workspace in an office or at home. Mount the Z2 mini behind your monitor or under your desk.
Industry leading security. Reliability you can trust
Get peace of mind with a PC that's built to endure. The Z2 Mini undergoes 360K hours of rigorous testing, military-standard testing and is certified for pro apps. And with HP Wolf Security for Business, it's protected below, in and above the OS.
Features | Intel® Core™ i7 processor
Run several CPU-heavy programs simultaneously without sacrificing performance with an Intel® Core™ i7 processor.
Multi-Display Support
See all your windows in perfect detail with support for up to 8 displays at 4K resolution
Tool-less Access
Evolve your work. Evolve your rig. With a tool-less sliding access cover, you can easily get into the the interior, and customize your Z to fit your needs.
Network Connectivity
Connect and collaborate quickly with 10Gb Ethernet interface.
Thermal Management
Innovatively designed to keep hardware components cool and quiet no matter how hard you push it. Have confidence to run your system at max load 24/7.
Custom Performance Modes
Take on the toughest workflows with three custom pre-set modes that optimize performance from the BIOS-High Performance, Performance and Quiet.
- Gigabit Ethernet offers great aggregate data transfer capacity which brings about less clog and better overall performance
- 280 W power supply unit (PSU) included
- Linux OS smartly manages your hardware and efficiently runs routine applications
- Intel Core i7 2.10 GHz processor offers lightning fast speed and peak performance even for the toughest tasks and processing intensive games
- With 32 GB of memory, users can run many programs without losing execution performance
Technical Specifications
| Chipset | |
| Chipset Manufacturer | Intel |
| Chipset Model | W680 |
| Operating System | |
| Operating System | Linux |
| Operating System Platform | Linux |
| Controllers | |
| RAID Levels | 0, 1 |
| Controller Type | NVMe |
| RAID Supported | Yes |
| Network & Communication | |
| Bluetooth | Yes |
| Wireless LAN | Yes |
| Ethernet Technology | Gigabit Ethernet |
| Storage | |
| Drive Type | SSD |
| Solid State Drive Interface | PCI Express NVMe |
| Total Solid State Drive Capacity | 512 GB |
| Display & Graphics | |
| Graphics Controller Model | RTX A2000 |
| Graphics Memory Capacity | 12 GB |
| Graphics Memory Accessibility | Dedicated |
| Maximum Memory Bandwidth | 288 GB/s |
| Power Description | |
| Input Voltage | 120 V AC |
| 230 V AC | |
| Frequency | 60 Hz |
| 50 Hz | |
| Maximum Power Supply Wattage | 280 W |
| Memory | |
| Error Checking | Non-ECC |
| Maximum Memory Supported | 64 GB |
| Standard Memory | 32 GB |
| Memory Technology | DDR5 SDRAM |
| Memory Configuration | 1 x 32GB |
| Total Number of Memory Slots | 2 |
| Physical Characteristics | |
| Weight (Approximate) | 5.29 lb (2400 g) |
| Form Factor | Mini PC |
| Cooler Type | Air Cooler |
| Height | 2.72" (69 mm) |
| Width | 8.31" (211 mm) |
| Depth | 8.58" (218 mm) |
| General Information | |
| Product Type | Workstation |
| Manufacturer Part Number | B4UY0UA#ABA |
| Manufacturer Website Address | http://www.hp.com |
| Manufacturer | HP Inc. |
| Product Name | Z2 Mini G9 Workstation |
| Product Series | Z2 Mini G9 |
| Brand Name | HP |
| Miscellaneous | |
| Package Contents |
|
| Energy Star | Yes |
| TCO Certified | Yes |
| Energy Efficiency Certification | China Energy Conservation Program (CECP) |
| Energy Efficiency Compliance | Energy-related Products Directive (ErP) |
| Environmental Compliance | Waste Electrical and Electronic Equipment Directive (WEEE) |
| Restriction of Hazardous Substances (RoHS) | |
| Interfaces/Ports | |
| DisplayPort | Yes |
| Number of DisplayPort Outputs | 2 |
| Total Number of USB Ports | 6 |
| Mini DisplayPort | Yes |
| Number Of Ethernet Ports | 1 |
| USB Type-C | Yes |
| USB Type-C Detail | 2 x SuperSpeed USB Type-C 20Gbps signaling rate |
| Number of Mini DisplayPort | 4 |
| Optional Ports | Details regarding optional ports aggregated from the information available for this product's family/series. Flex IO, choice of:
|
| Processor | |
| Processor Speed | 2.10 GHz |
| Processor Type | Core i7 |
| Processor Socket | Socket LGA-1700 |
| L3 Cache | 33 MB |
| Processor Model | i7-14700 |
| Processor Core | Icosa-core (20 Core) |
| Number of Processors Supported | 1 |
| Number of Processors Installed | 1 |
| Processor Generation | 14th Gen |
| Processor Threads | 28 |
