Intel
XEON P E5607 8M 2.26 GHZ 4.80 GT/S QPI FC-LGA10 MM#909770
XEON P E5607 8M 2.26 GHZ 4.80 GT/S QPI FC-LGA10 MM#909770
VPN:BX80614E5607 SKU:RSC426004 UPC:5032037011518
- With 8 MB integrated Level 3 cache, frequently used data can be instantly accessed
- Built on 32 nm technology and uses a high-k metal gate to enable higher performing transistors on the same node reducing leakage of currents
- Intel® Xeon® DP 2.26 GHz processor offers great stability when you are dealing with 3D rendering software or playing games. Integrated ECC-memory reduces the chance of critical system crashes.
Couldn't load pickup availability
Volume discount available - Ask for quote..
View full details
Recently Viewed
XEON P E5607 8M 2.26 GHZ 4.80 GT/S QPI FC-LGA10 MM#909770
Product information summary

About the product
Intel Xeon processor 5600 series automatically regulates power consumption and intelligently adjusts server performance according to application demand, maximizing both energy cost savings and performance.
The secret to this surprising combination is Intel's new 32nm microarchitecture. Featuring Intel Intelligent Power Technology, it reduces energy cost over single core servers by automatically shifting the CPU and memory into the lowest available power state, while Intel Turbo Boost Technology intelligently adjusts performance to application needs.
- With 8 MB integrated Level 3 cache, frequently used data can be instantly accessed
- Built on 32 nm technology and uses a high-k metal gate to enable higher performing transistors on the same node reducing leakage of currents
- Intel® Xeon® DP 2.26 GHz processor offers great stability when you are dealing with 3D rendering software or playing games. Integrated ECC-memory reduces the chance of critical system crashes.
- The Socket B LGA-1366 socket allows processor to be placed on the PCB without soldering
Technical Specifications
Miscellaneous | |
Platform Supported | PC |
Power Description | |
Thermal Design Power | 80 W |
Physical Characteristics | |
Width | 1.67" (42.50 mm) |
Depth | 1.77" (45 mm) |
General Information | |
Product Type | Processor |
Manufacturer Part Number | BX80614E5607 |
Manufacturer Website Address | http://www.intel.com |
Manufacturer | Intel Corporation |
Product Model | E5607 |
Product Name | Xeon DP Quad-core E5607 2.26GHz Processor |
Product Line | Xeon DP |
Product Series | 5600 |
Brand Name | Intel |
Technical Information | |
Bus Speed | 2400 MHz |
Process Technology | 32 nm |
Clock Speed | 2.26 GHz |
Processor Socket | Socket B LGA-1366 |
L1 Cache | 256 KB |
L2 Cache | 1 MB |
L3 Cache | 8 MB |
Processor Technology | Demand Based Switching |
Enhanced SpeedStep Technology | |
Virtualization Technology | |
Trusted Execution Technology | |
Extended Memory 64 Technology | |
Processor Core | Quad-core (4 Core) |
64-bit Processing | Yes |
Processor Manufacturer | Intel |
QuickPath Interconnect | 4.80 GT/s |
