About the product
Catalyst 1200 24-Port Ge, Full Poe, 4X1G Sfp,8000 Mac Address Table, Support,Jumbo Frame Sizes Up To 9000 Bytes,Support Ieee 802.3Az ,Ieee 802.1Ad ,Ieee 802.1X, Layer 2 And Layer 3 ,Flash 512 Mb ,Dual-Core Arm At 1.4 Ghz,1 Gb Ddr4 ,Limited Lifetime Warranty
Technical Specifications
| Primary Information | |
| Network Device Type: | Switch |
| Model: | C1200-24FP-4G |
| Form Factor: | Rack-Mountable |
| Connectivity Technology: | Wired |
| Data Transfer Rate: | 1 Gbps |
| Networking / Ports Qty: | 31 |
| Data Link Protocol: | Gigabit Ethernet |
| Processor / Type: | ARM |
| RAM / Total Installed Size: | 1 GB |
| Flash Memory / Installed Size: | 512 MB |
| Networking Compliant Standards: | IEEE 802.3az ,IEEE 802.1ad ,IEEE 802.1X |
| Media Layer Supported: | Layer 2 and Layer 3 |
| Power / Device Type: | Power Supply |
| Power / Voltage Required: | 100 to 240V 50 to 60 Hz |
| MTBF: | 698220 hours |
| Features: | Easy configuration and management;Reliability and performance; Flexible and compact design. |
| Network | |
| Power Over Ethernet (PoE) Support: | Yes |
| PoE Power Consumption: | 375W |
| MAC Address Table Size: | 8000 |
| Jumbo Frame Support: | up to 9000 bytes |
| Remote Management Protocol: | DHCP; IPv4; HTTPS; TFTP; IPv6; HTTP; SNMP |
| Routing Protocol: | IPv4 ,IPv6,Layer 3,CIDR |
| Authentication Method: | RADIUS authentication |
| SFP Ports: | 4 |
| Interfaces: | 10/100/1000 PoE+;SFP;USB Type C;RJ-45 console |
| Interfaces / Ports | |
| Interfaces: | 10/100/1000 PoE+;SFP;USB Type C;RJ-45 console |
| SFP Ports: | 4 |
| Dimensions&Miscellaneous | |
| Width: | 17.5 Inch |
| Depth: | 13.59 Inch |
| Height: | 1.73 Inch |
| Weight: | 4.6 Kg |
| Service&Support | |
| Service & Support Type: | Limited lifetime |
| Special Feature | |
| Min Operating Temperature: | -5 Celsius |
| Max Operating Temperature: | 50 Celsius |
| Min Storage Temperature: | -25 Celsius |
| Max Storage Temperature: | 70 Celsius |
| COO: | Inquire |
| TAA compliance: | Inquire |
| UNSPSC Code | |
| UNSPSC Code: | 43222612 |
