About the product
Catalyst 1300 16-Port Ge, Full Poe, 2X1G Sfp16000 Mac Address Table, Support,Jumbo Frame Sizes Up To 9000 Bytes,Supportieee 802.3Az ,Ieee 802.1Ad ,Ieee 802.1X,Ieee 802.3Af/At, Layer 2 And Layer 3 ,Flash 512 Mb ,Dual-Core Arm At 1.4 Ghz,1 Gb Ddr4 ,Limited Lifetime Warranty
Technical Specifications
| Primary Information | |
| Network Device Type: | Switch |
| Model: | C1300-16FP-2G |
| Form Factor: | Rack-Mountable |
| Connectivity Technology: | Wired |
| Data Transfer Rate: | 1 Gbps |
| Networking / Ports Qty: | 21 |
| Data Link Protocol: | Gigabit Ethernet |
| Processor / Type: | ARM |
| RAM / Total Installed Size: | 1 GB |
| Flash Memory / Installed Size: | 512 MB |
| Networking Compliant Standards: | IEEE 802.3az ,IEEE 802.1ad ,IEEE 802.1X,IEEE 802.3af/at |
| Media Layer Supported: | Layer 2 and Layer 3 |
| Power / Device Type: | Power Supply |
| Power / Voltage Required: | 100-240V 50-60 Hz |
| MTBF: | 706983 hours |
| Features: | The switches also support text view, a full Command-Line Interface (CLI) option for partners that prefer it. |
| Network | |
| Power Over Ethernet (PoE) Support: | Yes |
| PoE Power Consumption: | 240W |
| MAC Address Table Size: | 16000 |
| Jumbo Frame Support: | up to 9000 bytes |
| Remote Management Protocol: | DHCP; HTTPS; TFTP; HTTP; SNMP |
| Routing Protocol: | IPv4 ,IPv6,,CIDR |
| Authentication Method: | RADIUS accounting |
| SFP Ports: | 2 |
| Interfaces: | 10/100/1000 PoE+;SFP;USB Type C;RJ-45 console |
| Interfaces / Ports | |
| Interfaces: | 10/100/1000 PoE+;SFP;USB Type C;RJ-45 console |
| SFP Ports: | 2 |
| Dimensions&Miscellaneous | |
| Width: | 10.56 Inch |
| Depth: | 12.14 Inch |
| Height: | 1.73 Inch |
| Weight: | 2.49 Kg |
| Service&Support | |
| Service & Support Type: | limited lifetime warranty |
| Special Feature | |
| Min Operating Temperature: | -5 Celsius |
| Max Operating Temperature: | 50 Celsius |
| Min Storage Temperature: | -25 Celsius |
| Max Storage Temperature: | 70 Celsius |
| COO: | Inquire |
| TAA compliance: | Inquire |
| UNSPSC Code | |
| UNSPSC Code: | 43222612 |
