Cisco Catalyst 1300-24Xt - Switch - 24 Ports - Smart - Rack-Mountable

Name: Cisco Catalyst 1300-24Xt - Switch - 24 Ports - Smart - Rack-Mountable
Brand: Cbw140Ac
SKU: T851059
Price: 3573.43 CAD
Availability: InStock

$3,573.43 CAD

~~$3,930.78 CAD~~ $3,573.43 CAD

-9% OFF Ask for quote

Shipping calculated at checkout.

Catalyst 1300 24-Port 10Ge, 4X10G Sfp+ Shared

VPN:C1300-24XT SKU:T851059 UPC:889728521567

Quantity

Volume discount available - Ask for quote..

View full details

Product information summary

Cisco Catalyst 1300-24Xt - Switch - 24 Ports - Smart - Rack-Mountable

About the product

The Cisco Catalyst 1300-24XT switch is part of the fully managed switch line that delivers reliable and secure connectivity for small business networks. These switches accelerate your digital transformation by delivering full Layer 2/3 capabilities, an intuitive web dashboard, advanced networking features, and PoE+ support.

Technical Specifications

Primary Information
Product Description:	Cisco Catalyst 1300-24XT - switch - 24 ports - smart - rack-mountable
Device Type:	Switch - 24 ports - L3 - smart
Enclosure Type:	Rack-mountable
Subtype:	10 Gigabit Ethernet
Ports:	24 x 10 Gigabit Ethernet + 4 x combo 10 Gigabit SFP+/RJ-45
Performance:	Forwarding rate (64?byte packets): 357.12 Mpps ¦ Switching capacity: 480 Gbps
Capacity:	MSTP instances: 8 ¦ RPVST+ instances: 126 ¦ Link aggregation groups: 8 ¦ Link aggregation ports: 8 ¦ VLAN IDs: 4093 ¦ IGMP multicast groups: 2000 ¦ IPv4 routes (static): up to 990 ¦ IPv4 interfaces: 128 ¦ ACL rules: 1024 ¦ Priority queues: 8 ¦ Packet buffer size: 1.5 MB
MAC Address Table Size:	16000 entries
Jumbo Frame Support:	9000 bytes
Routing Protocol:	STP, static IP routing, RSTP, MSTP, IGMP, IGMPv2, IGMPv3, CIDR, RIP-2, policy-based routing (PBR), MLD, MLDv2
Remote Management Protocol:	CLI, SNMP, Telnet, SSH, SSH-2, DHCP, SCP, HTTPS, HTTP, ICMP, TFTP, Syslog, SNMP 2c, SNMP 3, RMON, RADIUS
Features:	Fanless, VLAN support, STP support, CLI management, ATP, FHS, QoS, sFlow, dynamic routing, Zero-Touch Deployment, Port Security, Web authentication, Address Resolution Protocol, ARP inspection, IP source guard, DHCP snooping, IPMB, NDP, router advertisement guard, DHCPv6 guard, layer 3 routing, LAG, port mirroring, eco-friendly button, EEE, RSTP, MSTP support, PVST+, RPVST+, LACP, Protocol-based VLANs support, MAC based VLAN, VLAN management, Private VLAN, PVE, Guest VLAN, GVRP, CPE VLAN, Auto Surveillance VLAN, MVR, Q-in-Q tunneling, TPID, GARP, UDLD, DHCP relay, DHCP server, IGMP snooping, IGMP querier, IGMP proxy, HoL Blocking Prevention, loopback detection, ACL support, BOOTP support, UDP, High Availability, MAC address authentication, BPDU Guard, STP Root Guard, STP loop guard, DAI, DoS protection, SCT, SSD, trustworthy systems, Broadcast Storm Control, Multicast Storm Control, Storm Control, Unicast Storm Control, Unknown Storm Control, DoS attack prevention, WRR, ToS, DSCP based CoS, DiffServ support, TCP congestion, iSCSI traffic optimization, path MTU discovery, DAD, RA guard, MLD snooping, MLD proxy, Telnet server, DNS client, Telnet client, DHCP client, Cisco NG PnP Protocol, IPv4 and IPv6 dual stack, VLAN mirroring, RSPAN, SCP, chip guard, boot integrity, persistent PoE, PoE scheduling, time-based port operation, cable length detection, LLDP, LLDP-MED, reset button
Compliant Standards:	IEEE 802.1x, IEEE 802.3az, IEEE 802.1D, IEEE 802.1w, IEEE 802.1s, IEEE 802.3ad (LACP), IEEE 802.1Q, IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ae, IEEE 802.3an, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z, IEEE 802.3af, IEEE 802.3at
Power:	AC 100-240 V (50/60 Hz)
Dimensions (WxDxH):	17.5 in x 9.4 in x 1.7 in
Weight:	6.13 lbs
Manufacturer Warranty:	Limited lifetime warranty
General
Device Type:	Switch - 24 ports - L3 - smart
Enclosure Type:	Rack-mountable
Subtype:	10 Gigabit Ethernet
Ports:	24 x 10 Gigabit Ethernet + 4 x combo 10 Gigabit SFP+/RJ-45
Performance:	Forwarding rate (64?byte packets): 357.12 Mpps ¦ Switching capacity: 480 Gbps
Capacity:	MSTP instances: 8 ¦ RPVST+ instances: 126 ¦ Link aggregation groups: 8 ¦ Link aggregation ports: 8 ¦ VLAN IDs: 4093 ¦ IGMP multicast groups: 2000 ¦ IPv4 routes (static): up to 990 ¦ IPv4 interfaces: 128 ¦ ACL rules: 1024 ¦ Priority queues: 8 ¦ Packet buffer size: 1.5 MB
MAC Address Table Size:	16000 entries
Jumbo Frame Support:	9000 bytes
Routing Protocol:	STP, static IP routing, RSTP, MSTP, IGMP, IGMPv2, IGMPv3, CIDR, RIP-2, policy-based routing (PBR), MLD, MLDv2
Remote Management Protocol:	CLI, SNMP, Telnet, SSH, SSH-2, DHCP, SCP, HTTPS, HTTP, ICMP, TFTP, Syslog, SNMP 2c, SNMP 3, RMON, RADIUS
Encryption Algorithm:	SSL, MD5
Authentication Method:	RADIUS, TACACS+
Features:	Fanless, VLAN support, STP support, CLI management, ATP, FHS, QoS, sFlow, dynamic routing, Zero-Touch Deployment, Port Security, Web authentication, Address Resolution Protocol, ARP inspection, IP source guard, DHCP snooping, IPMB, NDP, router advertisement guard, DHCPv6 guard, layer 3 routing, LAG, port mirroring, eco-friendly button, EEE, RSTP, MSTP support, PVST+, RPVST+, LACP, Protocol-based VLANs support, MAC based VLAN, VLAN management, Private VLAN, PVE, Guest VLAN, GVRP, CPE VLAN, Auto Surveillance VLAN, MVR, Q-in-Q tunneling, TPID, GARP, UDLD, DHCP relay, DHCP server, IGMP snooping, IGMP querier, IGMP proxy, HoL Blocking Prevention, loopback detection, ACL support, BOOTP support, UDP, High Availability, MAC address authentication, BPDU Guard, STP Root Guard, STP loop guard, DAI, DoS protection, SCT, SSD, trustworthy systems, Broadcast Storm Control, Multicast Storm Control, Storm Control, Unicast Storm Control, Unknown Storm Control, DoS attack prevention, WRR, ToS, DSCP based CoS, DiffServ support, TCP congestion, iSCSI traffic optimization, path MTU discovery, DAD, RA guard, MLD snooping, MLD proxy, Telnet server, DNS client, Telnet client, DHCP client, Cisco NG PnP Protocol, IPv4 and IPv6 dual stack, VLAN mirroring, RSPAN, SCP, chip guard, boot integrity, persistent PoE, PoE scheduling, time-based port operation, cable length detection, LLDP, LLDP-MED, reset button
Compliant Standards:	IEEE 802.1x, IEEE 802.3az, IEEE 802.1D, IEEE 802.1w, IEEE 802.1s, IEEE 802.3ad (LACP), IEEE 802.1Q, IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ae, IEEE 802.3an, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z, IEEE 802.3af, IEEE 802.3at
Processor:	X ARM: 1.4 GHz
RAM:	1 GB DDR4 SDRAM
Flash Memory:	512 MB
Status Indicators:	System, link/activity/speed, PoE
Expansion / Connectivity
Interfaces:	24 x 10GBase-T RJ-45 ¦ 4 x 10GBase-T/10GBase-X RJ-45/SFP+ ¦ 1 x console RJ-45 ¦ 1 x USB-C console ¦ 1 x USB ¦ 1 x RJ-45
Power
Power Device:	Internal power supply
Voltage Required:	AC 100-240 V (50/60 Hz)
Power Consumption Operational:	78.6 Watt
Power Consumption Stand by:	37.8 Watt
Miscellaneous
Included Accessories:	Pointer card, mounting kit
MTBF:	2,165,105 hours
Compliant Standards:	Plug and Play, RFC768, RFC783, RFC791, RFC792, RFC793, RFC813, RFC826, RFC879, RFC896, RFC854, RFC855, RFC856, RFC858, RFC894, RFC919, RFC920, RFC922, RFC950, RFC951, RFC1042, RFC1071, RFC1123, RFC1141, RFC1155, RFC1157, RFC1213, RFC1215, RFC1286, RFC1350, RFC1442, RFC1451, RFC1493, RFC1533, RFC1541, RFC1542, RFC1573, RFC1624, RFC1643, RFC1700, RFC1757, RFC1867, RFC1907, RFC2011, RFC2012, RFC2013, RFC2030, RFC2131, RFC2132, RFC2233, RFC2576, RFC2616, RFC2618, RFC2665, RFC2666, RFC2674, RFC2737, RFC2819, RFC2863, RFC3164, RFC3176, RFC3411, RFC3412, RFC3413, RFC3414, RFC3415, RFC3416, RFC4330, RFC4443, RFC4291, RFC2460, RFC4861, RFC4862, RFC1981, RFC4007, RFC3484, RFC5214, RFC4293, RFC3595, CSA 22.2, FCC CFR47 Part 15, UL 62368, WEEE
Dimensions & Weight
Width:	17.5 in
Depth:	9.4 in
Height:	1.7 in
Weight:	6.13 lbs
Manufacturer Warranty
Service & Support:	Limited warranty - return to factory - lifetime ¦ Technical support - 1 year
