About the product
The Cisco Catalyst 1300 Series Switches are fixed, managed, enterprise-class Gigabit Ethernet Layer 3 switches designed for small and medium-sized business and branch offices. These simple, flexible, and secure switches are ideal for deployment out of the wiring closet. The Catalyst 1300 Series operates on customized Linux OS software, with an intuitive dashboard that simplifies network setup and advanced features that accelerate digital transformation, while pervasive security protects business-critical transactions. The 1300 Series switches provide the ideal combination of affordability and capabilities for small and medium-sized businesses and help you create a more efficient, better-connected workforce. When your business needs advanced networking features and security for the digital transformation, yet value is still a top consideration, youre ready for the Cisco Catalyst 1300 Series Switches.
Technical Specifications
| Primary Information | |
| Network Device Type: | Switch |
| Model: | C1300-8MGP-2X |
| Form Factor: | Rack-Mountable |
| Connectivity Technology: | Wired |
| Data Transfer Rate: | 10 Gbps |
| Data Link Protocol: | 10 Gigabit Ethernet |
| Processor / Type: | Dual-Core |
| RAM / Total Installed Size: | 1 GB |
| Flash Memory / Installed Size: | 512 MB |
| Networking Compliant Standards: | IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z,IEEE 802.3x, IEEE 802.3s |
| Power / Device Type: | Power Supply |
| Media Layer Supported: | Layer 2 and Layer 3 |
| Power / Voltage Required: | 100-240V 50-60 Hz |
| MTBF: | 561618 hours |
| Features: | The Cisco Catalyst 1300 Series Switches provide the advanced feature set that growing businesses require and that high-bandwidth applications and technologies demand. They provide the following benefits. |
| Network | |
| Power Over Ethernet (PoE) Support: | yes |
| PoE Power Consumption: | 120W |
| MAC Address Table Size: | 16000 addresses |
| Jumbo Frame Support: | up to 9000 bytes |
| Remote Management Protocol: | DHCP; IPv4; IPv6; SSH; SNMP |
| Routing Protocol: | RIP v2 |
| Encryption Algorithm: | SSL |
| Authentication Method: | RADIUS |
| SFP+ Ports: | 2 |
| Interfaces: | 4 Gigabit Ethernet + 4 x 2.5G + 2 x 10G SFP+ |
| Interfaces / Ports | |
| Interfaces: | 4 Gigabit Ethernet + 4 x 2.5G + 2 x 10G SFP+ |
| SFP+ Ports: | 2 |
| Dimensions&Miscellaneous | |
| Width: | 10.56 Inch |
| Depth: | 12.72 Inch |
| Height: | 1.73 Inch |
| Weight: | 2.64 Kg |
| Service&Support | |
| Service & Support Type: | Limited lifetime with return-to-factory replacement |
| Special Feature | |
| Min Operating Temperature: | -5 celsius |
| Max Operating Temperature: | 50 celsius |
| Min Storage Temperature: | -25 celsius |
| Max Storage Temperature: | 70 celsius |
| COO: | Inquire |
| TAA compliance: | Inquire |
| UNSPSC Code | |
| UNSPSC Code: | 43222612 |
