About the product
With support for the higher memory speeds, enhanced memory capacity, and four-socket scalability, Intel® Xeon® Gold processors deliver significant improvement in performance, advanced reliability, and hardware-enhanced security. It is optimized for demanding mainstream data center, multi-cloud compute, and network and storage workloads. With up-to four-socket scalability, it is suitable for an expanded range of workloads.
- 24.75 MB of L3 cache offers supreme performance for computation intensive apps
- 24.75 MB of L3 cache to boost the instruction processing and system performance
- 14 nm enables improved performance per watt and micro architecture makes it power-efficient
- The processor upgrade features Socket 3647 socket for installation on the PCB
- The Socket 3647 socket allows processor upgrade to be placed on the PCB without soldering
Technical Specifications
| Environmental Conditions | |
| Thermal Specification | 188.6°F (87°C) |
| Power Description | |
| Thermal Design Power | 125 W |
| Physical Characteristics | |
| Width | 2.99" (76 mm) |
| Depth | 2.22" (56.50 mm) |
| General Information | |
| Product Type | Processor Upgrade |
| Manufacturer Part Number | UCS-CPU-I5220 |
| Manufacturer Website Address | http://www.cisco.com |
| Manufacturer | Cisco Systems, Inc |
| Product Model | 5220 |
| Product Name | Xeon Gold Octadeca-core 5220 2.20GHz Server Processor Upgrade |
| Product Line | Xeon Gold |
| Brand Name | Cisco |
| Technical Information | |
| Process Technology | 14 nm |
| Clock Speed | 2.20 GHz |
| Processor Socket | Socket 3647 |
| L3 Cache | 24.75 MB |
| Processor Core | Octadeca-core (18 Core) |
| 64-bit Processing | Yes |
| Processor Manufacturer | Intel |
| Overclocking Speed | 3.90 GHz |
| Processor Threads | 36 |
