About the product
Supermicro's mini-sized SC510 1U chassis features a depth of only 11.3" with advanced air flow / thermal design for client nodes, firewall applications, mail servers, web servers & other server applications. It supports a wide range of single processor based Micro ATX 9.6" x 9.6" motherboards. SC510T also supports dual 2.5" hot-swap drive bays, easy for upgrade and maintenance. In addition the SC510 is a perfect solution for home/office servers, with system noise level running at low 30 dB under the normal operation.
- Rack-mountable size for convenient installation and smooth operations
- Supports micro ATX motherboard to provide a significant number of PCI slots, expansion slots and peripheral ports with enhanced heat dissipation capability
Technical Specifications
| Bays | |
| "Number of Internal 2.5"" Bays" | 2 |
| I/O Expansions | |
| Total Number of Expansion Slots | 1 |
| Power Description | |
| Input Voltage | 110 V AC |
| 220 V AC | |
| Number of Power Supplies Installed | 1 |
| Power Supply Wattage | 200 W |
| Technical Information | |
| Motherboard Supported | Micro ATX |
| Features | Reset Button |
| LED Display | |
| On/Off Button | |
| Number of Fans Supported | 3 |
| Physical Characteristics | |
| Form Factor | Rack-mountable |
| Cooler Type | Fan Cooler |
| Height | 1.70" (43.18 mm) |
| Width | 17.20" (436.88 mm) |
| Depth | 11.30" (287.02 mm) |
| Compatible Rack Unit | 1U |
| Product Color | Black |
| Color Family | Black |
| General Information | |
| Product Type | Server Case |
| Manufacturer Part Number | CSE-510T-203B |
| Manufacturer Website Address | http://www.supermicro.com |
| Manufacturer | Supermicro Computer, Inc |
| Product Model | SC510T-203B |
| Product Name | SuperChassis 510T-203B |
| Product Line | SuperChassis |
| Product Series | SC510 |
| Brand Name | Supermicro |
