CSE-825TQ-600LPB 2U RM 8BAY BLACK 600W PFC EATX/ATX SC825TQ LP

Name: CSE-825TQ-600LPB 2U RM 8BAY BLACK 600W PFC EATX/ATX SC825TQ LP
Brand: Super Micro
SKU: RSC134653
Price: 847.19 CAD
Availability: OutOfStock

$847.19 CAD

~~$948.85 CAD~~ $847.19 CAD

-10% OFF Ask for quote

Shipping calculated at checkout.

Super Micro Supermicro SuperChassis SC825TQ-600LPB System Cabinet - Rack-mountable - Black - 2U - 11 x Bay - 1 x 600 W - ATX, EATX Motherboard Supported - 3 x Fan(s) Supported - 1 x External 5.25" Bay - 8 x External 3.5" Bay - 2 x Internal 3.5" Bay - 7x Slot(s) - 2 x USB(s)

VPN:CSE-825TQ-600LPB SKU:RSC134653 UPC:672042097937

Conveniently install a rack. 3 x fan(s) and 2U rack units to enable operational activities on the go.
Supports ATX motherboards to provide a significant number of PCI slots, expansion slots and peripheral ports with enhanced heat dissipation capability
11 expansion bays provide enough space to lodge numerous PC components

Quantity

Volume discount available - Ask for quote..

View full details

Product information summary

CSE-825TQ-600LPB 2U RM 8BAY BLACK 600W PFC EATX/ATX SC825TQ LP

About the product

Conveniently install a rack. 3 x fan(s) and 2U rack units to enable operational activities on the go.
Supports ATX motherboards to provide a significant number of PCI slots, expansion slots and peripheral ports with enhanced heat dissipation capability
11 expansion bays provide enough space to lodge numerous PC components

Technical Specifications

I/O Expansions
Total Number of Expansion Slots	7
Miscellaneous
Package Contents	SuperChassis SC825TQ-600LPB System Cabinet 1 x Backplane 1 x SC825/826/216/213 Intel DP X9,X8 PC air shroud 1368x13/12x13 1 x Accessories Box for SC825 with one power cords, NO FDD acc. 1 x ROUND 16 TO 16 PIN RIBBON FP CABLE 30 1 x Black DVD dummy cover for SC825, 836 1 x Front control board Dual color LED(FP836-D)forSC823M,825,825M,828,829,835,836 1 x Black USB/COM port tray for SC825, 836 8 x Black 3.5" HDD tray 2 x Black fixed 3.5 1 x PWS dummy cover (76mm wide, 700W/800W/900W), PBF 1 x Rail set, quick/quick, default for 2,3U 17.2"W 1 x LP Rear Window for SC825,825M,826,213,216
Interfaces/Ports
Front USB	Yes
Total Number of USB Ports	2
Bays
"Number of External 3.5"" Bays"	8
"Number of External 5.25"" Bays"	1
"Number of Internal 3.5"" Bays"	2
Number of Total Expansion Bays	11
Technical Information
Motherboard Supported	EATX
	ATX
Number of Fans Supported	3
Number of Fans Installed	3
Power Description
Input Voltage	220 V AC
	110 V AC
Number of Power Supplies Supported	1
Number of Power Supplies Installed	1
Power Supply Wattage	600 W
Physical Characteristics
Weight (Approximate)	50 lb (22679.62 g)
Form Factor	Rack-mountable
Height	3.50" (88.90 mm)
Width	17.20" (436.88 mm)
Depth	25.50" (647.70 mm)
Compatible Rack Unit	2U
Product Color	Black
Color Family	Black
General Information
Product Type	Server Case
Manufacturer Part Number	CSE-825TQ-600LPB
Manufacturer Website Address	http://www.supermicro.com
Manufacturer	Supermicro Computer, Inc
Product Model	SC825TQ-600LPB
Product Name	SuperChassis SC825TQ-600LPB System Cabinet
Product Line	SuperChassis
Product Series	SC825
Brand Name	Supermicro
