About the product
Doorbird IP Video Door Fingerprint 50, Surface Mount, Powder-Coated RAL 9016. DoorBird is the smart solution for your front door. Connect your DoorBird IP video door station to your smartphone and talk to your visitors while you're on the go! The IP video door station can be operated as a stand-alone unit or integrated into an existing smart home platform. You can also continue to use existing, classic installations such as electric door and gate openers with DoorBird and control them via the app.
Doorbird D1101FV-RAL9016 Video Door Fingerprint Features:
- Open API: Local interface for integration with third-party systems and SIP
- Video and audio call: On smartphones, tablets (iOS, Android), IP and landline phones (SIP)
- Smart Transmission Mode (STM): Real-time audio/video communication, optimized for mobile devices via WiFi, 3G, 4G, 5G
- Smart Home & NVR compatible: Control4, Loxone, Crestron, Synology, AVM FRITZ!Fon, URC, QNAP, RTI, ELAN, Fibaro, Bang & Olufsen and others
- Microphone: Clear voice transmission
- Automatic door buzzer: For use in medical offices and office environments
- Free visitor history: Store still images for free, with optional video recording available
- Individual action schedules, e.g.:
- Switch relay 1 for automatic door release Mon-Fri from 9 am until 4 pm when the call button is pressed
- 4D motion sensor switches on external lamp between 9 pm and 6 am
- Geofencing: Automatic door and gate opening when returning home
- Night vision: With Infrared LEDs
- HDTV Video: Ultra wide-angle, hemispheric lens, 180°
- Light sensor: For night vision mode
- One freely configurable bistable latching relay:
- Control one door or one gate via the App
- Status configurable via App: temporary or permanent circuit
- Easy self-install: Quick installation via QR code scan
- Call button: With a backlit nameplate
- Motion sensor with 4D technology: Distance up to 6 m (19.7 ft) adjustable via App (interval: 1 m/ 3.3 ft)
- Noise reduction and echo cancellation (AEC, ANR)
- Easy connection to the network
- Connection via a network cable or bell wire via 2-Wire Ethernet PoE Converter “DooBird A1071” (PoE, network data)
- WiFi-enabled: Works within a WiFi network, no LAN cable is needed
- Fingerprint reader
- Supported number of fingerprints: 50
- Status LED (RGB)
- Touch sensor
Doorbird D1101FV-RAL9016 Video Door Fingerprint Specifications:
GENERAL
- Front panel 3 mm (0.12 in), stainless steel, powder-coated, semi-gloss mounting housing Polycarbonate
- Type of mounting Surface-mounted, and flush-mounted variants are available separately
- Call button Illuminated nameplate Plastic
- Power supply 15 V DC (max. 15 W) or Power over Ethernet (PoE 802.3af Mode-A)
- Weight 785g
Fingerprint Reader
- Configurable via App
- Individual events (e.g. switch a relay, HTTP(s)
- request)
- individual schedules
- 50 fingerprints manageable
- Event History
- Multicolored Status LED
- Normal mode: Green + success sound: successfully
- authenticated
- Red + error sound: unrecognized fingerprint
- (e.g. unknown fingerprint or wet touch sensor
- field - dry it with a tissue)
- Pink: Manipulation prevention (too many
- failed attempts, locked out for a min. 30
- seconds)
- Enrollment mode:
- Blue: wait for finger to touch
- Green + no sound: scan step successful
- Green + success sound: entire scan step
- successful (enrollment done)
- LED goes off: Timeout during enrollment
- Start-up mode:
- Yellow: Hardware test successful
- Red: Hardware test not successful (broken)
- Power supply: 15 V DC (max. 15 W) or Power over
- Ethernet (PoE 802.3af Mode-A)
- Weight 785 g
- Connectors: LAN/PoE (T+, T-, R+, R-)
- Bistable latching relay, max. 1-24 V DC/AC, 1 A, e.g. for the electric door opener
- External input for the external door opener
- button
- 15 V DC input (+, -), max. 15 W
- Relays can be expanded/detached with
- DoorBird I/O Door Controller
- Weatherproof Yes, IP65
- Approvals IP65, CE, FCC, IC, RoHS, REACH, IEC/EN 62368, IEC/EN 62471, Wi-Fi CERTIFIED™
- Dimensions 213,4 x 85 x 32 mm (H x W x D) 6.77 x 3.35 x 1.26 in (H x W x D)
- Operating conditions -25 to +55°C / -13 to 131°F
- Humidity 10 to 85 % RH (non-condensing)
VIDEO
- Camera HDTV 1080p, dynamic (VGA – HDTV)
- Lens High-end ultra wide-angle hemispheric lens 180° (D), 150° (H), 82° (V), straightened, IR-capable
- Night vision Yes, light sensor, automatic IR-cut filter, Infrared LEDs (850 nm)
AUDIO
- Audio components Speaker and microphone, noise reduction, and echo cancellation (ANR, AEC)
- Audio streaming Two-way, full duplex
Technical Specifications
Doorbird IP Video Door Fingerprint 50, Surface Mount, Powder-Coated RAL 9016. DoorBird is the smart solution for your front door. Connect your DoorBird IP video door station to your smartphone and talk to your visitors while you're on the go! The IP video door station can be operated as a stand-alone unit or integrated into an existing smart home platform. You can also continue to use existing, classic installations such as electric door and gate openers with DoorBird and control them via the app.
Doorbird D1101FV-RAL9016 Video Door Fingerprint Features:
- Open API: Local interface for integration with third-party systems and SIP
- Video and audio call: On smartphones, tablets (iOS, Android), IP and landline phones (SIP)
- Smart Transmission Mode (STM): Real-time audio/video communication, optimized for mobile devices via WiFi, 3G, 4G, 5G
- Smart Home & NVR compatible: Control4, Loxone, Crestron, Synology, AVM FRITZ!Fon, URC, QNAP, RTI, ELAN, Fibaro, Bang & Olufsen and others
- Microphone: Clear voice transmission
- Automatic door buzzer: For use in medical offices and office environments
- Free visitor history: Store still images for free, with optional video recording available
- Individual action schedules, e.g.:
- Switch relay 1 for automatic door release Mon-Fri from 9 am until 4 pm when the call button is pressed
- 4D motion sensor switches on external lamp between 9 pm and 6 am
- Geofencing: Automatic door and gate opening when returning home
- Night vision: With Infrared LEDs
- HDTV Video: Ultra wide-angle, hemispheric lens, 180°
- Light sensor: For night vision mode
- One freely configurable bistable latching relay:
- Control one door or one gate via the App
- Status configurable via App: temporary or permanent circuit
- Easy self-install: Quick installation via QR code scan
- Call button: With a backlit nameplate
- Motion sensor with 4D technology: Distance up to 6 m (19.7 ft) adjustable via App (interval: 1 m/ 3.3 ft)
- Noise reduction and echo cancellation (AEC, ANR)
- Easy connection to the network
- Connection via a network cable or bell wire via 2-Wire Ethernet PoE Converter “DooBird A1071” (PoE, network data)
- WiFi-enabled: Works within a WiFi network, no LAN cable is needed
- Fingerprint reader
- Supported number of fingerprints: 50
- Status LED (RGB)
- Touch sensor
Doorbird D1101FV-RAL9016 Video Door Fingerprint Specifications:
GENERAL
- Front panel 3 mm (0.12 in), stainless steel, powder-coated, semi-gloss mounting housing Polycarbonate
- Type of mounting Surface-mounted, and flush-mounted variants are available separately
- Call button Illuminated nameplate Plastic
- Power supply 15 V DC (max. 15 W) or Power over Ethernet (PoE 802.3af Mode-A)
- Weight 785g
Fingerprint Reader
- Configurable via App
- Individual events (e.g. switch a relay, HTTP(s)
- request)
- individual schedules
- 50 fingerprints manageable
- Event History
- Multicolored Status LED
- Normal mode: Green + success sound: successfully
- authenticated
- Red + error sound: unrecognized fingerprint
- (e.g. unknown fingerprint or wet touch sensor
- field - dry it with a tissue)
- Pink: Manipulation prevention (too many
- failed attempts, locked out for a min. 30
- seconds)
- Enrollment mode:
- Blue: wait for finger to touch
- Green + no sound: scan step successful
- Green + success sound: entire scan step
- successful (enrollment done)
- LED goes off: Timeout during enrollment
- Start-up mode:
- Yellow: Hardware test successful
- Red: Hardware test not successful (broken)
- Power supply: 15 V DC (max. 15 W) or Power over
- Ethernet (PoE 802.3af Mode-A)
- Weight 785 g
- Connectors: LAN/PoE (T+, T-, R+, R-)
- Bistable latching relay, max. 1-24 V DC/AC, 1 A, e.g. for the electric door opener
- External input for the external door opener
- button
- 15 V DC input (+, -), max. 15 W
- Relays can be expanded/detached with
- DoorBird I/O Door Controller
- Weatherproof Yes, IP65
- Approvals IP65, CE, FCC, IC, RoHS, REACH, IEC/EN 62368, IEC/EN 62471, Wi-Fi CERTIFIED™
- Dimensions 213,4 x 85 x 32 mm (H x W x D) 6.77 x 3.35 x 1.26 in (H x W x D)
- Operating conditions -25 to +55°C / -13 to 131°F
- Humidity 10 to 85 % RH (non-condensing)
VIDEO
- Camera HDTV 1080p, dynamic (VGA – HDTV)
- Lens High-end ultra wide-angle hemispheric lens 180° (D), 150° (H), 82° (V), straightened, IR-capable
- Night vision Yes, light sensor, automatic IR-cut filter, Infrared LEDs (850 nm)
AUDIO
- Audio components Speaker and microphone, noise reduction, and echo cancellation (ANR, AEC)
- Audio streaming Two-way, full duplex
