About the product
Doorbird Compact is an IP Video Door Station with Surface Mount and is Powder-Coated RAL 9016. DoorBird is the smart solution for your front door. Connect your DoorBird IP video door station to your smartphone and talk to your visitors while you're on the go! The IP video door station can be operated as a stand-alone unit or integrated into an existing smart home platform. You can also continue to use existing, classic installations such as electric door and gate openers with DoorBird and control them via the app.
Doorbird D1101V-RAL9016 Compact IP Video Door Station Features:
- Open API: Local interface for integration with third-party systems and SIP
- Video and audio call: On smartphones, tablets (iOS, Android), IP and landline phones (SIP)
- Smart Transmission Mode (STM): Real-time audio/video communication, optimized for mobile devices via WiFi, 3G, 4G, 5G
- Smart Home & NVR compatible: Control4, Loxone, Crestron, Synology, AVM FRITZ!Fon, URC, QNAP, RTI, ELAN, Fibaro, Bang & Olufsen and others
- Microphone: Clear voice transmission
- Automatic door buzzer: For use in medical offices and office environments
- Free visitor history: Store still images for free, with optional video recording available
- Individual action schedules, e.g.:
- Switch relay 1 for automatic door release Mon-Fri from 9 am until 4 pm when the call button is pressed
- 4D motion sensor switches on external lamp between 9 pm and 6 am
- Geofencing: Automatic door and gate opening when returning home
- Night vision: With Infrared LEDs
- HDTV Video: Ultra wide-angle, hemispheric lens, 180°
- Light sensor: For night vision mode
- One freely configurable bistable latching relay:
- Control one door or one gate via the App
- Status configurable via App: temporary or permanent circuit
- Easy self-install: Quick installation via QR code scan
- Call button: With a backlit nameplate
- Motion sensor with 4D technology: Distance up to 6 m (19.7 ft) adjustable via App (interval: 1 m/ 3.3 ft)
- Noise reduction and echo cancellation (AEC, ANR)
- Easy connection to the network
- Connection via a network cable or bell wire via 2-Wire Ethernet PoE Converter “DooBird A1071” (PoE, network data)
- WiFi-enabled: Works within a WiFi network, no LAN cable is needed
Doorbird D1101V-RAL9016 Compact IP Video Door Station Specifications:
GENERAL
- Front panel 3 mm (0.12 in), stainless steel, powder-coated, semi-gloss mounting housing Polycarbonate
- Type of mounting Surface-mounted, and flush-mounted variants are available separately
- Call button Illuminated nameplate Plastic
- Power supply 15 V DC (max. 15 W) or Power over Ethernet (PoE 802.3af Mode-A)
- Weight 471 g
- Connections: LAN/PoE (T+, T-, R+, R-)
- Bistable latching switching relay #1, max 1-24 V DC/V AC, 1 amp, e.g. for the electric door opener
- External input for external door opener button (potential-free)
- 15 V DC input (+, -), max. 15 W Weatherproof Yes, IP65
- Approvals IP65, CE, FCC, IC, RoHS, REACH, IEC/EN 62368, IEC/EN 62471, Wi-Fi CERTIFIED™
- Dimensions 151.9 x 65 x 32 mm (H x W x D)5.98 x 2.56 x 1.26 in (H x W x D)
- Operating conditions: -25 to +55°C / -13 to 131°F
- Relative humidity 10 to 85% (non-condensing)
- Internet: High-speed landline broadband Internet connection, DSL, cable or fiber optic, no socks or proxy server
- Network: Ethernet network, with DHCP, Recommended mounting height the camera lens should be at least 145 cm (57 in).
- VIDEO
- camera HDTV 1080p, dynamic (VGA - HDTV) lens high-end ultra wide-angle hemispherical lens 180° (D), 150° (H), 82° (V), equalized, IR-capable
- Night vision Yes, light sensor, automatic IR-Cut filter, Infrared LEDs (850 nm)
- AUDIO
- Audio components Speaker and microphone, echo and noise cancellation (AEC, ANR)
- Audio streaming Two-way, full duplex
