About the product
The DoorBird Internet Firewall module adds an additional layer of network security, ensuring access control solutions are hardened against unauthorized access or malicious intrusion on all DoorBird access control systems— from single-building installs, to apartments, commercial and business, and more.
Attackers attempting to access the local area internet to intrude into door access systems, or external hackers gaining entrance into larger systems are prevented from manipulating doors by cordoning off connected DoorBird products and preventing unauthorized and unknown network traffic—all while still maintaining easy-to-access remote networking features for authorized users—without complicated port-forwarding, network re-routing or expensive and risky 3rd party solutions.
Installs easily via plug & play, flexibly adapts to IP whitelisting conditions. Remotely configurable by admins to adjust settings anywhere, any time. PoE or screw terminal 15VDC powered, networking cables not included.
DB-FW-A1051 Specs and Features
- Dimensions: 104 × 75 × 34 mm (L × W × H)
- Power supply: 15 V DC or Power over Ethernet (PoE IEEE 802.3 af or higher)
- Power consumption: 1 W
- Operating conditions: 0°C to +55°C / 32°F to 131°F
- Relative air humidity: 0 % to 85 % (non-condensing)
- Protection class: IP 30
- Mounting: Top-hat rail / DIN rail/Wall mounting
- Certifications: CE, FCC, IC, RoHS, WEEE, UKCA
- Connections & interface: 2× RJ45 port (10/100 Base-T), 1× screw terminal 15 V DC input (-/+)
- Display: LCD status display
- Backlight Colour: Blue
- Network status display
- PWR LED
- Functions:
- Network filter: Actively filters network traffic and blocks unauthorized access
- DHCP server: Integrated DHCP server (10.223.x.x), up to 1,000 devices
- IP whitelist: Approval of IP addresses or domains, such as for control functions of smart home systems
- System requirements:
- Mobile devices: Latest iOS on iPhone/iPad, latest Android on smartphone/tablet
- Internet: High-speed landline Broadband internet connection, DSL, cable or glass fiber, no SOCKS or proxy server
- Network: Ethernet network with DHCP
- Compatible with all DoorBird IP video door stations and DoorBird peripheral devices
- What's Included:
- 1 × A1051 Internet Firewall
- 1 × Installation manual
- 1 × Quick-start guide with digital passport
- 1 × Hardware
- Weight: 155 g
Technical Specifications
The DoorBird Internet Firewall module adds an additional layer of network security, ensuring access control solutions are hardened against unauthorized access or malicious intrusion on all DoorBird access control systems— from single-building installs, to apartments, commercial and business, and more.
Attackers attempting to access the local area internet to intrude into door access systems, or external hackers gaining entrance into larger systems are prevented from manipulating doors by cordoning off connected DoorBird products and preventing unauthorized and unknown network traffic—all while still maintaining easy-to-access remote networking features for authorized users—without complicated port-forwarding, network re-routing or expensive and risky 3rd party solutions.
Installs easily via plug & play, flexibly adapts to IP whitelisting conditions. Remotely configurable by admins to adjust settings anywhere, any time. PoE or screw terminal 15VDC powered, networking cables not included.
DB-FW-A1051 Specs and Features
- Dimensions: 104 × 75 × 34 mm (L × W × H)
- Power supply: 15 V DC or Power over Ethernet (PoE IEEE 802.3 af or higher)
- Power consumption: 1 W
- Operating conditions: 0°C to +55°C / 32°F to 131°F
- Relative air humidity: 0 % to 85 % (non-condensing)
- Protection class: IP 30
- Mounting: Top-hat rail / DIN rail/Wall mounting
- Certifications: CE, FCC, IC, RoHS, WEEE, UKCA
- Connections & interface: 2× RJ45 port (10/100 Base-T), 1× screw terminal 15 V DC input (-/+)
- Display: LCD status display
- Backlight Colour: Blue
- Network status display
- PWR LED
- Functions:
- Network filter: Actively filters network traffic and blocks unauthorized access
- DHCP server: Integrated DHCP server (10.223.x.x), up to 1,000 devices
- IP whitelist: Approval of IP addresses or domains, such as for control functions of smart home systems
- System requirements:
- Mobile devices: Latest iOS on iPhone/iPad, latest Android on smartphone/tablet
- Internet: High-speed landline Broadband internet connection, DSL, cable or glass fiber, no SOCKS or proxy server
- Network: Ethernet network with DHCP
- Compatible with all DoorBird IP video door stations and DoorBird peripheral devices
- What's Included:
- 1 × A1051 Internet Firewall
- 1 × Installation manual
- 1 × Quick-start guide with digital passport
- 1 × Hardware
- Weight: 155 g
