About the product
The Elo TouchSystems 1509L 15" Desktop Touchmonitor is an attractively designed wide screen touchmonitor solution, primarily intended for general applications including hospitality and retail environments. Without compromising the principles of 'built for touch' and high quality upon which the Elo TouchSystems brand prides itself, the 1509L has been designed to fit the tightest of budgets
The 1509L's 15-inch widescreen format is intended to save space physically, while offering additional on-screen space. This allows for extra content such as additional sidebar menus, on-screen keypads or additional columns of information. In addition, the widescreen design prevents blocking eye contact to customers and improves customer interaction.
- LED backlight enhances the display performance to deliver an outstanding color range and contrast ratio
- The 300:1 contrast ratio produces enhanced sharpness and shading accuracy in each picture
- Enjoy crisp content and energetic hues with the 220 cd/m² brightness
- Furnishes captivating visuals with about 220 cd/m² brightness levels
Technical Specifications
| Interfaces/Ports | |
| USB | Yes |
| VGA | Yes |
| Miscellaneous | |
| Country of Origin | China |
| Mean Time Between Failures (MTBF) | 5.7 Year |
| Touchscreen Information | |
| Touchscreen Type | IntelliTouch Surface Wave |
| Touchscreen | Yes |
| Power Description | |
| Input Voltage Range | 100V to 240V |
| Operating Power Consumption | 11 W |
| Standby Power Consumption | 1.80 W |
| Off-Mode Power Consumption | 1 W |
| Video | |
| Contrast Ratio | 300:1 |
| Brightness | 220 cd/m² |
| Color Supported | 16.7 Million Colors |
| Maximum Resolution | 1366 x 768 |
| Native Contrast Ratio | 400:1 |
| General Information | |
| Product Type | LCD Touchscreen Monitor |
| Manufacturer Part Number | E534869 |
| Manufacturer Website Address | http://www.elotouch.com |
| Manufacturer | Elo Touch Solutions, Inc |
| Product Model | 1509L |
| Product Name | 1509L 15" LCD Desktop Touchmonitor |
| Brand Name | Elo |
| Physical Characteristics | |
| Weight (Approximate) | 5.29 lb (2400 g) |
| Height | 11.22" (285 mm) |
| Width | 15.43" (392 mm) |
| Depth | 8.98" (228 mm) |
| VESA Mount Compatible | Yes |
| VESA Mount Standard | 75 x 75 |
| Height with Stand | 9.51" (241.50 mm) |
| Width with Stand | 15.44" (392.20 mm) |
| Depth with Stand | 11.35" (288.30 mm) |
| Product Color | Black |
| Technical Information | |
| Aspect Ratio | 16:9 |
| Response Time | 8 ms |
| Features | On-screen Display (OSD) |
| Dust Resistant | |
| Cable Management | |
| Water Proof | |
| Mount Type | Pole Mount |
| Wall Mountable | |
| Viewable Screen Size | 15.6" |
| Screen Mode | WXGA |
| Horizontal Viewing Angle | 80° |
| Vertical Viewing Angle | 40° |
| Backlight Technology | LED |
| Panel Technology | Thin Film Transistor (TFT) |
| Horizontal Frequency | 30 kHz to 80 kHz |
| Curved Screen | No |
| Vertical Frequency | 60 Hz |
| Screen Size Class | 16" |
