About the product
Zebra incorporated extensive customer feedback, as well as the legacy of our industry leading Stripe and S4M printers, to create the new ZT200 Series family of printers with elegant space saving design, effortless setup, intuitive user operation, and ease of service and maintenance.
Technical Specifications
| Fonts & Emulation | |
| Language Emulation | ZPL |
| Interfaces/Ports | |
| USB | Yes |
| Serial Port | Yes |
| Memory | |
| Flash Memory | 128 MB |
| Standard Memory | 128 MB |
| Memory Technology | DRAM |
| Power Description | |
| Input Voltage | 220 V AC |
| 110 V AC | |
| Power Source | AC Supply |
| Physical Characteristics | |
| Weight (Approximate) | 7.71 kg |
| Height | 11" (279.40 mm) |
| Width | 9.40" (238.76 mm) |
| Depth | 17" (431.80 mm) |
| Miscellaneous | |
| Package Contents |
|
| Platform Supported | PC |
| Certifications & Standards |
|
| Environmentally Friendly | Yes |
| Energy Star | Yes |
| General Information | |
| Product Type | Direct Thermal Printer |
| Manufacturer Part Number | ZT22042-D11000FZ |
| Manufacturer Website Address | http://www.zebra.com |
| Manufacturer | Zebra Technologies Corporation |
| Product Model | ZT220 |
| Product Name | ZT220 Industrial Printer |
| Product Series | ZT200 |
| Brand Name | Zebra |
| Media Types & Handling | |
| Media Thickness | 10 mil |
| Maximum Roll Diameter | 8" |
| Media Type | Notch |
| Linered Label | |
| Label | |
| Die-cut Label | |
| Continuous Label | |
| Black Mark | |
| Media Sensor | Transmissive Media Sensor |
| Reflective Media Sensor | |
| Label Core Size | 3" (76.20 mm) |
| Maximum Label Width | 4.50" (114.30 mm) |
| Maximum Label Length | 39" (990.60 mm) |
| Technical Information | |
| Application/Usage | Industrial |
| Barcode Symbology Supported | Code 128-C |
| Code 39 | |
| Code 49 | |
| Code 93 | |
| Data Matrix | |
| EAN With 2 or 5 Digit Extension | |
| EAN-13 | |
| EAN-8 | |
| Industrial 2 of 5 | |
| Interleaved 2 of 5 | |
| ISBT-128 | |
| LOGMARS | |
| Maxi Code | |
| Micro PDF | |
| Micro PDF-417 | |
| Codabar | |
| PDF-417 | |
| Planet Code | |
| Plessey | |
| POSTNET | |
| QR Code | |
| RSS-14 | |
| Standard 2 of 5 | |
| TLC 39 | |
| UCC Case Codes | |
| UPC 2 or 5 Digit Extension | |
| UPC-A | |
| UPC-E | |
| Code 128-B | |
| Codablock | |
| MSI | |
| Aztec Code | |
| Code 128-A | |
| Code 11 | |
| Maximum Print Width | 4.09" |
| Recommended Use | Label Print |
| Features | Element Energy Equalizer |
| Clear Bi-fold Media Side Door | |
| Bi-color LED | |
| Print Technology | Direct Thermal |
| Peel Facility | Yes |
| Print Color Capability | Monochrome |
| Maximum Print Resolution (dpi) | 203 |
