About the product
- Perfect for applications that require direct association with a workstation or a notebook
- Laser-free design provides high-performance scanning without the risk of eye injury
Technical Specifications
| Interfaces/Ports | |
| Host Interface | USB |
| Miscellaneous | |
| Package Contents |
|
| Compatibility | HP Retail Point of Sale Systems |
| Platform Supported | PC |
| Environmentally Friendly | Yes |
| Ingress Protection (IP) Rating | IP52 |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| General Information | |
| Product Type | Barcode Scanner |
| Manufacturer Part Number | 5YQ08AA |
| Manufacturer Website Address | http://www.hp.com |
| Packaged Quantity | 1 |
| Manufacturer | HP Inc. |
| Product Name | Engage Imaging Barcode Scanner II |
| Brand Name | HP |
| Physical Characteristics | |
| Weight (Approximate) | 5.68 oz (161 g) |
| Form Factor | Handheld |
| Length | 6.54" (166 mm) |
| Height | 4.29" (109 mm) |
| Width | 2.68" (68 mm) |
| Product Color | Black |
| Color Family | Black |
| Technical Information | |
| Barcode Symbology Supported | 1D:
Postal decode symbologies:
Stacked decode symbologies:
|
| Connectivity Technology | Cable |
| Light Source | LED |
| Drop Specification | 6.0 ft (1.8 m) |
| Scan Pattern | Omni-directional |
| Image Sensor Type | Imager |
| Stand Included | Yes |
| Cable Type Included | USB |
| Scanning Capability | 2D |
| 1D | |
| Reading Angle (Skew) | 65° |
| Reading Angle (Pitch) | 65° |
| Reading Angle (Roll) | 360° |
| Maximum Ambient Light | 100000 lux |
| Minimum Print Contrast | 15% |
| Minimum Element Resolution (Code 39) | 5 mil (0.13 mm) |
| Maximum Element Resolution (Code 39) | 10 mil (0.25 mm) |
| Minimum Element Resolution (DataMatrix) | 10 mil (0.25 mm) |
| Maximum Element Resolution (DataMatrix) | 15 mil (0.38 mm) |
| Maximum Element Resolution (PDF417) | 10 mil (0.25 mm) |
