About the product
The 24-Port PoE All-Gigabit Managed Switch operates at peak efficiency thanks to its high performance switching engine. It is quite dependable, has a big buffer, and has a short gearbox delay. Additionally, it optimises transmission performance when viewing Ultra HD videos and possesses a powerful switching capability. Because of its all-metal construction, the device can operate in temperatures between -10°C and 55°C (+14°F and +131°F) with excellent heat dissipation and low power consumption. The switch provides good resistance against interference from static electricity, lightning, and pulses, while also providing protection against overvoltage, EMC, and overcurrent from power input terminals. It also supports a variety of web and network management software applications that are SNMP-based, and it has strong network management features.
Dahua 24-Port PoE Desktop Managed Gigabit Switch (PoE++) Features:
- Layer 2 Network Management PoE Ethernet Switch
- Gigabit Ports
- Total PoE Budget 360W
- Eighteen (26) 1000 Mbps Ethernet Ports and Two (2) 1000 Mbps Uplink Optical Ports
- Supports IEEE802.3af, IEEE802.3at, Hi-PoE, and IEEE802.3bt Standards
- Supports PoE 2.0: Enhanced power capabilities with advanced features
- BT 90W (Red Port): Compliant with IEEE 802.3bt, delivering up to 90W for high-power devices
- Long Distance PoE: Offers up to 250m (820.21 ft) connection range
- PoE Watchdog (PD Alive): Ensures 24/7 monitoring and automatic restart of PoE devices upon failure
- Intelligent PoE: Enables port priority to be assigned, ensuring that essential devices are powered
Dahua 24-Port PoE Desktop Managed Gigabit Switch (PoE++) Specifications:
- Hardware
- Power Adapter Included
- PoE Supported
- Ethernet Port 26
- Optical Port Two (2)
- Eternet Port Speed 10/100/1000 Mbps
- Optical Port Speed 1000 Mbps
- Description of Function Slots
- Port 1 to 24 24 × RJ45 10/100/1000 Mbps(PoE)
- Port 25 to 26 Two (2) × RJ45 10/100/1000 Mbps
- Port 27 to 28 Two (2) × SFP 1000 Mbps
- Debugging One (1) x Console
- Reset Button One (1)
- Performance
- Layer Layer 2
- Management Type Web (HTTP/HTTPS), Telnet, SNMP V1/V2C/V3
- MTBF 467,125.73 hours
- Switching Capacity 56 Gbps
- Packet Forwarding Rate 41.664 Mpps
- Packet Buffer Size 4.1 Mbit
- Jumbo Frame 10K Byte
- MAC Table Size 8K
- VLAN Number 4K
- VLAN Interface 10
- Dynamic ARP 512
- Communication Standard IEEE 802.3, IEEE 802.3u, IEEE 802.3x, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3ad
- Feature
- PoE Protocol IEEE802.3af (PoE), IEEE802.3at (PoE+), IEEE802.3bt (PoE++), Hi-PoE
- PoE Power
- Port 1 to 2 ? 90 W
- Port 3 to 16 ? 30 W
- Total ? 360 W
- PoE Power Consumption
- Management Supported
- PoE Pin Assignment 1,2,4,5 (V+),3,6,7,8 (V-)
- Long-Distance PoE Transmission Supported
- Spanning Tree Protocol STP, RSTP
- VLAN Function Supported
- Link Aggregation Static Link, LACP
- IEEE 802.3x Flow Control IEEE 802.3X-Based Flow Control (Full-Duplex)
- Multicast IGMP Snooping
- DHCP Client, Server, Snooping
- Security IEEE 802.1x, ACL
- Electrical
- Power Supply 100-240 VAC, 50/60 Hz, 3.5 A
- Power Consumption
- Idling Load ? 20 W
- Full Load 360 W
- Environmental
- Operating Temperature –10°C to 55°C (+14°F to +131°F)
- Operating Humidity 5% to 95% (RH)
- Statics Protection
- Air Discharge 8 kV
- Contact Discharge 6 kV
- Lighting Protection
- Common Mode 4 kV
- Differential Mode 2 kV
- Construction
- Net Weight 3.405 kg (7.51 lb)
- Gross Weight 4.51 kg (9.94 lb)
- Product Dimensions 440 mm × 300 mm × 44 mm (17.32 in. × 11.81 in. × 1.73 in.)
- Packaging Dimensions 525 mm × 410 mm × 110 mm (20.67 in. × 16.14 in. × 4.33 in.)
- Certifications
- CE IEC 62368-1:2014 EN 55032:2015+A11:2020+A1:2020 EN IEC 61000-3-2: 2019+A1:2021 EN 61000-3-3: 2013+A1: 2019+A2:2021 EN 55024: 2010+A1: 2015 EN 55035:2017+A11 :2020 EN 50130-4: 2011+A1: 2014
- FCC 47 CFR FCC PartlS, Subpart B, Class A ANSI C63.4:2014
Technical Specifications
The 24-Port PoE All-Gigabit Managed Switch operates at peak efficiency thanks to its high performance switching engine. It is quite dependable, has a big buffer, and has a short gearbox delay. Additionally, it optimises transmission performance when viewing Ultra HD videos and possesses a powerful switching capability. Because of its all-metal construction, the device can operate in temperatures between -10°C and 55°C (+14°F and +131°F) with excellent heat dissipation and low power consumption. The switch provides good resistance against interference from static electricity, lightning, and pulses, while also providing protection against overvoltage, EMC, and overcurrent from power input terminals. It also supports a variety of web and network management software applications that are SNMP-based, and it has strong network management features.
Dahua 24-Port PoE Desktop Managed Gigabit Switch (PoE++) Features:
- Layer 2 Network Management PoE Ethernet Switch
- Gigabit Ports
- Total PoE Budget 360W
- Eighteen (26) 1000 Mbps Ethernet Ports and Two (2) 1000 Mbps Uplink Optical Ports
- Supports IEEE802.3af, IEEE802.3at, Hi-PoE, and IEEE802.3bt Standards
- Supports PoE 2.0: Enhanced power capabilities with advanced features
- BT 90W (Red Port): Compliant with IEEE 802.3bt, delivering up to 90W for high-power devices
- Long Distance PoE: Offers up to 250m (820.21 ft) connection range
- PoE Watchdog (PD Alive): Ensures 24/7 monitoring and automatic restart of PoE devices upon failure
- Intelligent PoE: Enables port priority to be assigned, ensuring that essential devices are powered
Dahua 24-Port PoE Desktop Managed Gigabit Switch (PoE++) Specifications:
- Hardware
- Power Adapter Included
- PoE Supported
- Ethernet Port 26
- Optical Port Two (2)
- Eternet Port Speed 10/100/1000 Mbps
- Optical Port Speed 1000 Mbps
- Description of Function Slots
- Port 1 to 24 24 × RJ45 10/100/1000 Mbps(PoE)
- Port 25 to 26 Two (2) × RJ45 10/100/1000 Mbps
- Port 27 to 28 Two (2) × SFP 1000 Mbps
- Debugging One (1) x Console
- Reset Button One (1)
- Performance
- Layer Layer 2
- Management Type Web (HTTP/HTTPS), Telnet, SNMP V1/V2C/V3
- MTBF 467,125.73 hours
- Switching Capacity 56 Gbps
- Packet Forwarding Rate 41.664 Mpps
- Packet Buffer Size 4.1 Mbit
- Jumbo Frame 10K Byte
- MAC Table Size 8K
- VLAN Number 4K
- VLAN Interface 10
- Dynamic ARP 512
- Communication Standard IEEE 802.3, IEEE 802.3u, IEEE 802.3x, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3ad
- Feature
- PoE Protocol IEEE802.3af (PoE), IEEE802.3at (PoE+), IEEE802.3bt (PoE++), Hi-PoE
- PoE Power
- Port 1 to 2 ? 90 W
- Port 3 to 16 ? 30 W
- Total ? 360 W
- PoE Power Consumption
- Management Supported
- PoE Pin Assignment 1,2,4,5 (V+),3,6,7,8 (V-)
- Long-Distance PoE Transmission Supported
- Spanning Tree Protocol STP, RSTP
- VLAN Function Supported
- Link Aggregation Static Link, LACP
- IEEE 802.3x Flow Control IEEE 802.3X-Based Flow Control (Full-Duplex)
- Multicast IGMP Snooping
- DHCP Client, Server, Snooping
- Security IEEE 802.1x, ACL
- Electrical
- Power Supply 100-240 VAC, 50/60 Hz, 3.5 A
- Power Consumption
- Idling Load ? 20 W
- Full Load 360 W
- Environmental
- Operating Temperature –10°C to 55°C (+14°F to +131°F)
- Operating Humidity 5% to 95% (RH)
- Statics Protection
- Air Discharge 8 kV
- Contact Discharge 6 kV
- Lighting Protection
- Common Mode 4 kV
- Differential Mode 2 kV
- Construction
- Net Weight 3.405 kg (7.51 lb)
- Gross Weight 4.51 kg (9.94 lb)
- Product Dimensions 440 mm × 300 mm × 44 mm (17.32 in. × 11.81 in. × 1.73 in.)
- Packaging Dimensions 525 mm × 410 mm × 110 mm (20.67 in. × 16.14 in. × 4.33 in.)
- Certifications
- CE IEC 62368-1:2014 EN 55032:2015+A11:2020+A1:2020 EN IEC 61000-3-2: 2019+A1:2021 EN 61000-3-3: 2013+A1: 2019+A2:2021 EN 55024: 2010+A1: 2015 EN 55035:2017+A11 :2020 EN 50130-4: 2011+A1: 2014
- FCC 47 CFR FCC PartlS, Subpart B, Class A ANSI C63.4:2014
