About the product
Experience What DisplayPort 1.4 Has to Offer
This 8K DisplayPort cable supports all DP 1.4 features:
- Resolutions up to 8K at 60Hz
- HDCP 2.2 support
- High Bit Rate 3 (HBR3) bandwidth of 32.4Gbps
- High Dynamic Range (HDR)
- Multi-Stream Transport (MST) for daisy-chaining multiple monitors
- 32 uncompressed digital audio channels
- Backward compatible with 5K 60Hz, 4K 120Hz and previous generations of DP
Easy Installations
This durable yet lightweight active DP 1.4 cable features both copper and optical fiber conductors enabling a more flexible installation with minimal clutter. Plus, the cable features built-in amplifier circuitry which actively boosts the DisplayPort signal with no external power needed. The DisplayPort connectors also feature latches that provide a secure connection between your devices.
Comprised of a fiber and copper wire mix, this active cable is less susceptible to EMI interference, for a clear and reliable audio/video signal.
DP14MM15MAO is backed by a StarTech.com lifetime warranty and free lifetime technical support
Note: This cable features unidirectional architecture, please refer to the "display" label on the HDMI connectors to ensure installed in the correct direction.
More from the Manufacturer
- DISPLAYPORT 1.4 OPTICAL CABLE: 49.2'/15m hybrid copper & fiber DisplayPort 1.4 cable; 8K 60Hz (7680x4320), 4K 120Hz (3840x2160), 32.4Gbps, HDR10, HBR3, 32ch audio (5.1/7.1/Dolby TrueHD/Atmos), MST, GTC for precise audio channel timing; future-proof for 8K
- ACTIVE CIRCUITRY: DisplayPort Active Optical cable with unique DisplayPort bus powered Electro-Optical amplifier boosts video signals over longer distances up to 15 meters (49.2 feet) (no external power supply needed); Latching DP connectors
- RELIABLE DESIGN: DP Active Optical Cable (AOC) w/ flexible PVC jacket and strain relief absorb stress of frequent bends; Internal wire manager, metal connector sub-structure & Al-Mylar Foil with Braid provide EMI shielding & superior signal integrity
- APPLICATIONS: Ideal for home, office, boardroom, classroom; works w/ professional workstations: Dell XPS 11th Gen, HP Z2 G8 Tower with Radeon Vega Frontier/Pro WX Series/W5500/Pro Duo & NVIDIA Quadro P graphics cards; Use with Ultra HD (UHD) monitors/TV
- SPECS: 15 m (49.2 ft) | Black | DisplayPort version 1.4 cable | DP Male/Male Cord | PVC Jacket | Al-Mylar foil w/ Braid | DSC 1.2, HDCP 2.2 | Works w/ DP 1.3/1.2 (1080p/4K) | 2-Year Warranty | Note: DP connector labelled "Display End" connects to display
Technical Specifications
| Miscellaneous | |
| Compatibility |
|
| Country of Origin | Taiwan |
| Environmentally Friendly | Yes |
| General Information | |
| Product Type | Video Cable |
| Manufacturer Part Number | DP14MM15MAO |
| Manufacturer Website Address | http://www.startech.com |
| Packaged Quantity | 1 Each |
| Manufacturer | StarTech.com |
| Product Name | 15 m (49.2 ft.) Active Optical DisplayPort 1.4 Cable |
| Brand Name | StarTech.com |
| Physical Characteristics | |
| Shipping Weight (Approximate) | 1.43 lb (648.64 g) |
| Weight (Approximate) | 14.89 oz (422 g) |
| Shipping Height | 3.07" (77.98 mm) |
| Shipping Width | 10.43" (264.92 mm) |
| Jacket Material | Polyvinyl Chloride (PVC) |
| Product Color | Black |
| Color Family | Black |
| Technical Information | |
| Cable Length | 49.2 ft (15 m) |
| Data Transfer Rate | 32.4 Gbit/s |
| Device Supported | Projector |
| TV | |
| Graphics Card | |
| Audio/Video Device | |
| Desktop Computer | |
| Digital Signage Display | |
| Notebook | |
| Monitor | |
| Shielding | Yes |
| Features | Stress Resistant |
| Strain Relief | |
| Signal Booster | |
| Multi-Stream Transport (MST) Support | |
| Locking Latch | |
| Flexible | |
| EMI Protection | |
| Display Stream Compression (DSC) 1.2 | |
| Active | |
| HDCP 2.2 | |
| Latching Connector | |
| Cable Type | Fiber Optic |
| Connector Type on First End | DisplayPort 1.4 Digital Audio/Video - Male |
| Connector Type on Second End | DisplayPort 1.4 Digital Audio/Video - Male |
| Connector Plating | Nickel |
| American Wire Gauge | 28 AWG |
| Supported Resolution | 7680 x 4320 |
| Connector on First End Details | 1 x 20-pin DisplayPort 1.4 Digital Audio/Video - Male |
| Connector on Second End Details | 1 x 20-pin DisplayPort 1.4 Digital Audio/Video - Male |
| Connector Gender on First End | Male |
| Connector Gender on Second End | Male |
