About the product
Va Technology , 178 Ultra-Wide View Screen. 8 Bit Lvds Fhd (1920 1080) Display. 100 Hz Refresh Rate, More Fluid And Life-Like Video. Ultra-Thin Device Body With Ultra-Thin Border For 3 Sides. 3D Noise Reduction. Low Blue Light Design For Eye Care. Dual Interface Of Hdmi And Vga. Support Vesa Wall Mount. Built-In Speaker For Audio Input.
Technical Specifications
| Primary Information | |
| Model: | DS-D5024F2-BV2S |
| Display Format: | FHD |
| Display Technology: | Vertical Alignment(VA) Technology |
| Flat / Curved: | Flat |
| Max Resolution: | 1920 x 1080 |
| Display Diagonal Size: | 23.8 Inch |
| Display / Color Support: | 8-bit |
| Display / Response Time: | 7 Ms |
| Display / Refresh Rate: | 100 Hz |
| Dot Pitch / Pixel Pitch: | 0.0915 x 0.2745 Mm |
| Image Contrast Ratio: | 4000 : 1 |
| Brightness: | 250 cd/m2 |
| Viewing Angle: | 178/178 |
| Color Gamut: | NTSC 72% |
| Audio Output: | 2W Speakers x2 |
| Interfaces: | HDMI 1.4 × 1, VGA × 1, Audio IN × 1 |
| Video Interfaces: | HDMI; VGA |
| HDMI Ports Qty: | 1 |
| VGA Qty: | 1 |
| Power Consumption Operational: | 24 Watt |
| Power / Voltage Required: | DC 12V, 2.0A |
| Power Consumption Standby: | 0.5 W |
| VESA Mount Compatible: | 75 x 75 mm |
| Width: | 539.7 Mm |
| Depth: | 43.5 Mm |
| Height: | 327.33 Mm |
| Weight: | 2.85 Kg |
| Min Operating Temperature: | 0 Celsius |
| Max Operating Temperature: | 40 Celsius |
| Humidity Range Operating: | 20% to 90% RH (Non-Condensing) |
| Display | |
| Brightness: | 250 cd/m2 |
| Color Gamut: | NTSC 72% |
| Display / Color Support: | 8-bit |
| Display Diagonal Size: | 23.8 Inch |
| Dot Pitch / Pixel Pitch: | 0.0915 x 0.2745 Mm |
| Flat / Curved: | Flat |
| Power | |
| Power / Voltage Required: | DC 12V, 2.0A |
| Power Consumption Operational: | 24 Watt |
| Special Feature | |
| COO: | Inquire |
| TAA compliance: | Inquire |
| UNSPSC Code | |
| UNSPSC Code: | 43211902 |
