About the product
The Hikvision DS-KAD706Y-SP Video Intercom Distribution Module, 6 Interface.
Hikvision DS-KAD706Y-SP Two wire controllers Features:
- 6 cascade interfaces were used for connecting with DS-KAD706 and DS-KAD706-S
- 6 interface indicators for displaying network status
Hikvision DS-KAD706Y-SP Two wire controllers Specifications:
Interfaces
- Network Interface: 1 RJ45 (1-ch reserved terminal and 1-ch for WAN access)
- Two-wire: interface 6-ch for data exchanging
- Signal: indicator 6 indicators for displaying 6-ch signals
- Power: indicator 1
- Reset 1
General
- Power supply Two-wire mode, 24 VDC
- Power consumption:?7 W
- Working temperature: -10 °C to +40 °C (14 °F to +104 °F)
- Working humidity:10% to 90%
- Dimension 143.7mm × 92.4mm × 65.9mm (5.66"" × 3.64"" × 2.59"")
Technical Specifications
The Hikvision DS-KAD706Y-SP Video Intercom Distribution Module, 6 Interface.
Hikvision DS-KAD706Y-SP Two wire controllers Features:
- 6 cascade interfaces were used for connecting with DS-KAD706 and DS-KAD706-S
- 6 interface indicators for displaying network status
Hikvision DS-KAD706Y-SP Two wire controllers Specifications:
Interfaces
- Network Interface: 1 RJ45 (1-ch reserved terminal and 1-ch for WAN access)
- Two-wire: interface 6-ch for data exchanging
- Signal: indicator 6 indicators for displaying 6-ch signals
- Power: indicator 1
- Reset 1
General
- Power supply Two-wire mode, 24 VDC
- Power consumption:?7 W
- Working temperature: -10 °C to +40 °C (14 °F to +104 °F)
- Working humidity:10% to 90%
- Dimension 143.7mm × 92.4mm × 65.9mm (5.66"" × 3.64"" × 2.59"")
