About the product
Ax3000Ceilingmountdual-Bandwi-Fi6Accesspointport:1Xgigabitrj45Portspeed:574Mbpsat2.4Ghz+2402Mbpsat5Ghzfeature:802.3Atpoeand12Vdc(Poweradapterisnotincluded),3Xinternalantennasoneoftheantennasisanauxiliaryantennaforthe5Gfrequencyband,Whichenhancescoveragecapability,160Mhzsupported,Mu-Mimo,Seamlessroaming,Bandsteering,Beamforming,Loadbalance,Airtimefairness,Centralizedmanagementbyomadasdncontroller,Omadaapp
Technical Specifications
| Primary Information | |
| Product Type: | Access Point |
| Networking Type: | Ethernet |
| Data Transfer Rate: | 1 Gbps |
| Data Link Protocol: | Gigabit Ethernet |
| Frequency Band: | 2.4 GHz; 5 GHz |
| Connectivity Technology: | Wired |
| MIMO Type: | 2x2 MU-MIMO |
| Antenna Type: | Omni-directional |
| Model: | EAP653 UR |
| Features: | High-Efficiency WiFi 6;Gigabit Wired Performance; Ultra-Range Coverage;Centralized Cloud Management;802.3at PoE Powered;Auto Channel Selection and Power Adjustment;Omada Mesh Technology |
| Networking | |
| Transport Protocol: | Gigabit Ethernet |
| Networking Compliant Standards: | IEEE 802.11ax/ac/n/g/b/a, 802.3a |
| Remote Management Protocol: | HTTPS; HTTP; SSH; SNMP |
| Networking / Ports Qty: | 1 |
| Cellular Technology: | None |
| Cellular Service Provider: | None |
| Cellular Generation: | None |
| System Requirements | |
| Operating System: | Windows OS; Linux |
| Performance | |
| Concurrent Devices: | 250+ |
| Dimensions&Miscellaneous | |
| Width: | 6.3 Inch |
| Depth: | 6.3 Inch |
| Height: | 1.3 Inch |
| Power | |
| Power / Voltage Required: | 12V DC, 48V Passive PoE |
| Special Feature | |
| COO: | Inquire |
| TAA compliance: | Inquire |
