About the product
The Vertiv Liebert GXT5-3KL630RT2UXL uninterruptible power supply (UPS) protects critical equipment against outages and power disturbances. This single-phase, 3kVA online double conversion UPS comes with an L6-30P Input Cord. It offers continuous power conditioning in centralized and edge locations. With a high power factor (0.9-1.0), it allows more connected loads, saving space and costs. This compact rack mount/tower UPS has an optional Vertiv RDU101 communications card for remote monitoring and control to help enable faster event resolution. With the free Vertiv Power Insight software, monitor up to 100 distributed UPS units and receive simple notifications of their status and events in one place. This UPS has scalable runtime options with matching external battery cabinets for extra runtime during an outage to support critical equipment. This battery backup is ENERGY STAR 2.0 certified and comes with an intuitive, gravity-sensing, full-color LCD screen.
- Vertiv Liebert GXT5-3KL630RT2UXL: 2U double conversion online UPS with L6-30P Input Cord
- High Power Factor (0.9-1.0) provides more usable power and more connected loads, saves space and costs
- Remote management and configuration of UPS with optional Vertiv RDU101 network communication card
- Energy Star 2.0 certified UPS helps reduce operation cost with high normal operating efficiency
- Compact tower/rack mount design with intuitive, gravity sensing, colored graphic LCD display
Technical Specifications
| Controls/Indicators | |
| Status Indicators | Full Color Graphic LCD / Diagnostic LEDs:
|
| Warranty | |
| Additional Warranty Information | Opt. 2 year extension |
| Environmental Conditions | |
| Environmental Sensors | Humidity Sensor |
| Temperature Sensor | |
| Leak Detection Sensor | |
| Interfaces/Ports | |
| USB | Yes |
| VGA | No |
| Network (RJ-45) | Yes |
| Modem (RJ-11) | No |
| Serial Port | Yes |
| Total Number of Expansion Slots | 1 |
| Physical Characteristics | |
| Weight (Approximate) | 65.10 lb (29528.86 g) |
| Form Factor | Rack/Tower |
| Rack Height | 2U |
| Height | 3.35" (85 mm) |
| Width | 16.93" (430 mm) |
| Depth | 21.26" (540 mm) |
| Battery Information | |
| Battery Chemistry | Lead Acid |
| Hot Swappable | Yes |
| Backup/Run Time (Half Load) | 9 Minute |
| Backup/Run Time (Full Load) | 3 Minute |
| Battery Characteristics | Valve-regulated, Non-spillable |
| Number of External Battery Cabinets | 1 |
| Backup/Run Time With External Battery Cabinet (Full Load) | 17 Minute |
| Backup/Run Time With External Battery Cabinet (Half Load) | 43.50 Minute |
| General Information | |
| Product Type | Double Conversion Online UPS |
| Manufacturer Part Number | GXT5-3KL630RT2UXL |
| Manufacturer Website Address | http://www.vertiv.com/ |
| Packaged Quantity | 1 |
| Manufacturer | Vertiv |
| Product Name | GXT5 3kVA 208V UPS |
| Product Series | GXT |
| Brand Name | Vertiv Liebert |
| Miscellaneous | |
| Additional Information |
|
| Package Contents |
|
| Certifications & Standards | |
| Country of Origin | China |
| Environmentally Friendly | Yes |
| TAA Compliant | No |
| Energy Star | Yes |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| Registration, Evaluation, Authorization and Restriction of Chemicals (REACH) | |
| Power Description | |
| Input Voltage | 208 V AC |
| Output Voltage | 220 V AC |
| 230 V AC | |
| 240 V AC | |
| 200 V AC | |
| 208 V AC | |
| Waveform Type | Sine Wave |
| Input Frequency | 50 Hz |
| Load Capacity (VA) | 3 kVA |
| Load Capacity (Watt) | 3 kW |
| Utility (AC) Mode Overload |
|
| Technical Information | |
| Application/Usage | Data Center |
| Mission Critical Equipment | |
| Bypass Switch | Automatic & Manual |
| Internal | |
| Emergency Power OFF | Yes |
| Plug/Connector Type | NEMA L6-30P |
| Cord Length | 10 ft (3.05 m) |
| Phase | Single Phase |
| Receptacle Type | NEMA L6-30R |
| NEMA L6-15R | |
| Transfer Time | 0 ns |
| Receptacle Detail | 2 x NEMA L6-30R |
| 2 x NEMA L6-15R |
