About the product
The Cisco 809 Industrial Integrated Services Routers support the latest Third-Generation Partnership Project (3GPP) Release 9 Category 3 and Category 4 LTE standards. The routers provide persistent, reliable LTE connectivity transparent hand-offs between LTE and 3G networks.
The following models are available:
- IR809G-LTE-NA-K9: Multimode 4G, 3G, and 2G connectivity to cellular networks operating in LTE 1900 MHz (band 2 PCS), 1700/2100 MHz (band 4 AWS), 850 MHz (band 5), 700 MHz (band 17), and 1900 MHz (band 25 extended PCS) frequencies; backward-compatible with UMTS and HSPA+, at 850 MHz (band 5), 900 MHz (band 8), 1900 MHz (band 2 PCS), and 1700/2100 MHz (band 4 AWS).
- IR809G-LTE-VZ-K9: Multimode 4G, 3G, and 2G connectivity to cellular networks operating in LTE 700 MHz (band 13), 1700/2100 MHz (band 4 AWS), and 1900 MHz (band 25 extended PCS) frequencies; backward-compatible with EVDO Rev A/CDMA 1x BC0, BC1, and BC10.
- IR809G-LTE-LA-K9: Multimode 4G and 3G connectivity to cellular networks operating in FDD LTE 2100 MHz (band 1), 1800 MHz (band 3), 850 MHz (band 5), 2600 (band 7), 900 (band 8), 850 (band18, band19), 1500 (band 21), 700 (band 28), and TDD LTE 2600 (band 38), 1900 (band 39), 2300 (band 40), and 2500 (band 41); backward-compatible with WCDMA 2100 MHz (band 1), 850 MHz (band 5), 800 MHz (band 6, band 19), 900 MHz (band 8), 1700 MHz (band 9), and TD-SCDMA 1900 MHz (band 39).
- IR809G-LTE-GA-K9: Multimode 4G, 3G, and 2G connectivity to cellular networks operating in LTE 800 MHz (band 20), 900 MHz (band 8), 1800 MHz (band 3), 2100 MHz (band 1), and 2600 MHz (band 7) frequencies; backward-compatible with UMTS and HSPA+ at 850 MHz (band 5), 900 MHz (band 8), 1900 MHz (band 2), and 2100 MHz (band 1).
- Cost-effective, rapidly deployable, and secure backup solution is how you can describe the Integrated Services Router with wireless 3G
- Gigabit Ethernet port for ultra-fast wired network speeds
- Fits neatly into a panel and allows you to keep your cables tidy and organized
Technical Specifications
| Network & Communication | |
| VPN Supported | Yes |
| Ethernet Technology | Gigabit Ethernet |
| Interfaces/Ports | |
| USB | Yes |
| Number of Network (RJ-45) Ports | 2 |
| Number of Broadband (RJ-45) Ports | 2 |
| PoE (RJ-45) Port | No |
| Physical Characteristics | |
| Weight (Approximate) | 311.8 g |
| Form Factor | Rail-mountable |
| Door Mount | |
| Panel-mountable | |
| Height | 1.15" (29.21 mm) |
| Width | 5.05" (128.27 mm) |
| Depth | 6.27" (159.26 mm) |
| General Information | |
| Product Type | Wireless Integrated Services Router |
| Manufacturer Part Number | IR809G-LTE-LA-K9 |
| Manufacturer Website Address | http://www.cisco.com |
| Manufacturer | Cisco Systems, Inc |
| Product Model | 809 |
| Product Name | 809 Wireless Integrated Services Router |
| Product Series | 800 |
| Brand Name | Cisco |
| Wireless Specifications | |
| Broadband Transmission Technology | Cellular |
| Cellular Data Connectivity Technology | HSPA+ |
| UMTS | |
| LTE | |
| Cellular Generation | 4G |
| Cellular Network Supported | LTE 850 |
| LTE 900 | |
| WCDMA 1700 | |
| WCDMA 2100 | |
| WCDMA 800 | |
| WCDMA 850 | |
| WCDMA 900 | |
| LTE 1500 | |
| LTE 1800 | |
| LTE 1900 | |
| LTE 2100 | |
| LTE 2300 | |
| LTE 2500 | |
| LTE 2600 | |
| LTE 700 | |
| Total Wireless Transmission Speed | 18.75 MB/s |
