About the product
Part of the Cisco® 1000 Series Integrated Services Routers (ISR), the ISR 1100 Series and ISR 1100X Series are powered by Viptela® operating system or IOS XE SD-WAN operating system. These devices combine WAN and comprehensive security in a wired high-performance platform. The ISR 1100 Series and ISR 1100X Series combine an enterprise grade platform with best-in-class SD-WAN. The ISR 1100 Series come with 4GB DRAM, whereas the ISR 1100X Series offer 8GB DRAM.
- Offers cost-effective and reliable primary WAN connectivity in locations where wireline services such as DSL and ISDN are not available
- Gigabit Ethernet port for ultra-fast wired network speeds
- For USB-enabled devices accessibility, the router comes with a built-in USB port
Technical Specifications
| I/O Expansions | |
| Expansion Slot Type | SFP |
| Total Number of Expansion Slots | 2 |
| Interfaces/Ports | |
| USB | Yes |
| Number of Network (RJ-45) Ports | 3 |
| Number of Broadband (RJ-45) Ports | 1 |
| Miscellaneous | |
| Package Contents |
|
| Environmentally Friendly | Yes |
| Environmental Compliance | Waste Electrical and Electronic Equipment Directive (WEEE) |
| Physical Characteristics | |
| Weight (Approximate) | 2.67 lb (1211.09 g) |
| Height | 1.10" (27.94 mm) |
| Width | 10.20" (259.08 mm) |
| Depth | 7" (177.80 mm) |
| Network & Communication | |
| VPN Supported | Yes |
| Ethernet Technology | Gigabit Ethernet |
| Multi-SIM Supported | No |
| Number of SIM Card Supported | 1 |
| SIM Size Supported | Micro |
| Wireless Specifications | |
| Broadband Transmission Technology | Ethernet |
| Cellular | |
| Total Number of Antennas | 2 |
| Firewall Type | PAT |
| NAT | |
| General Information | |
| Product Type | Wireless Integrated Services Router |
| Manufacturer Part Number | ISR1100X-6G |
| Manufacturer Website Address | http://www.cisco.com |
| Manufacturer | Cisco Systems, Inc |
| Product Model | ISR1100X-6G |
| Product Name | ISR1100X-6G Integrated Services Router |
| Product Series | 1100X |
| Brand Name | Cisco |
