About the product
The Vertiv Liebert ITA2 MBC provides maximum system availability to business-critical equipment by allowing transfer of connected equipment to an alternate power path allowing full isolation of the UPS for maintenance. It is designed to be used with the Liebert ITA2 8kVA UPS model. The Liebert ITA2 MBC includes input and output circuit breakers, manual maintenance bypass breaker (make-before-break), two integral distribution POD ports, rack-mount rail kit and securing flanges (handles). It is compact, easy-to-use, and flexible with rackmount or tower configuration options. The Liebert ITA2 MBC has a 2-year warranty.
- Saves space, has small footprint
- Provides external wrap around power path for maintenance
- Easy to use, minimizes human error
- Can directly power rack PDUs and IT equipment with the addition of optional power output distributon modules (sold separately)
Technical Specifications
| Technical Information | |
| Plug/Connector Type | Hard Wire 4-wire |
| Power Description | |
| Input Voltage | 208 V AC |
| 120 V AC | |
| Current | 30 A |
| Load Capacity (VA) | 8 kW |
| Miscellaneous | |
| Additional Information |
|
| Package Contents |
|
| Compatibility | Liebert 8kVA UPS |
| Certifications & Standards |
|
| Country of Origin | China |
| Physical Characteristics | |
| Weight (Approximate) | 39.70 lb (18007.62 g) |
| Form Factor | Rack-mountable |
| Height | 10.30" (261.62 mm) |
| Width | 16.90" (429.26 mm) |
| Depth | 22.40" (568.96 mm) |
| General Information | |
| Product Type | Bypass Cabinet |
| Manufacturer Part Number | ITA2-08KMBC40 |
| Manufacturer Website Address | http://www.vertiv.com/ |
| Manufacturer | Vertiv |
| Product Model | 767041022315 |
| Product Name | ITA2 UPS 8kVA External Maintenance Bypass Cabinet Rack/Tower |
| Product Series | ITA2 |
| Brand Name | Vertiv Liebert |
