About the product
The Vertiv Liebert ITA2 cable kits allow converting the standard hard-wired connections to cord-n-plug connections for easy installation and servicing. The Liebert ITA2 Cable Kit P/N: ITA2-10KMBCSL2 contains (1) main input cord 10 ft. (3m) long with IEC60309-60A connector and (1) main output cord 1 ft. (305mm) long with IEC60309-60A connector. This cable kit can be used with a stand-alone 10kVA UPS (no external MBC), or as the main input/output of the 10kVA rated rack-mount MBC for a single input system. The input cord is 3 phase 4W+G and the output cord is 3 phase 3W+G.
- The cable kit allows cord-n-plug connections for easy installation and servicing
Technical Specifications
| Power Description | |
| Current Rating | 60 A |
| Miscellaneous | |
| Additional Information |
|
| Compatibility | Liebert 10kVA UPS |
| Country of Origin | China |
| Technical Information | |
| Device Supported | UPS |
| First End Connector Type | IEC 60309-60 |
| First End Connector Detail | 1 x 3-pin IEC 60309-60 Female |
| General Information | |
| Product Type | Standard Power Cord |
| Manufacturer Part Number | ITA2-10KMBCSL2 |
| Manufacturer Website Address | http://www.vertiv.com/ |
| Manufacturer | Vertiv |
| Product Model | 767041022414 |
| Product Name | ITA2 UPS 10kVA UPS-MBC Cordset - IEC60309-60A 4W+G-3W+G |
| Brand Name | Vertiv Liebert |
