About the product
The H3C RPS 800-A Redundant Power System is an external DC power supply unit for the H3C S5500-52C-EI that uses AC input and provides DC output for switch redundant backup power. This redundant power system (RPS) provides selective DC outputs. Depending on the connected DC output cable(s), the RPS can provide +12 V DC, -54 V DC, or +12 V DC and -54 V DC concurrently to the powered device. The RPS 800 supports cold backup of power supply, which means it only switches to the DC output state when it detects a power supply failure of the powered device.
Technical Specifications
| Miscellaneous | |
| Package Contents |
|
| Compatibility | HP 3Com Switches:
|
| Country of Origin | China |
| Physical Characteristics | |
| Weight (Approximate) | 8.38 lb (3800 g) |
| Form Factor | External |
| Height | 1.73" (44 mm) |
| Width | 17.36" (441 mm) |
| Depth | 7.17" (182 mm) |
| General Information | |
| Product Type | Redundant Power Supply |
| Manufacturer Part Number | JD183AABA |
| Manufacturer Website Address | http://www.hpe.com |
| Manufacturer | Hewlett Packard Enterprise |
| Product Name | H3C RPS 800 Redundant Power Supply |
| Brand Name | HPE |
| Power Description | |
| Input Voltage | 110 V AC |
| 220 V AC | |
| Output Power | 650 W |
| Output Voltage | 12 V DC |
| -54 V DC | |
| Output Current | 12 A |
| 17.25 A | |
| Input Voltage Range | 100 V AC - 240 V AC |
| Number of +12V Rails | 1 |
| Output Voltage Detail | -54 V DC @ 12 A |
| 12 V DC @ 17.25 A |
