About the product
The Aruba CX 6300 Switch Series is a modern, flexible, and intelligent family of AOS-CX stackable switches ideal for access, aggregation, and data center top-of-rack (TOR) deployments. With a cloud-centric design that combines a fully programmable OS with the Aruba Network Analytics Engine, the Aruba CX 6300 extends industry-leading monitoring and troubleshooting capabilities to the access layer. Support of Aruba NetEdit and the Aruba CX Mobile App verify that configurations are flawless and easy to deploy. A powerful Aruba Gen7 ASIC architecture delivers fast, non-blocking performance, meaning your network is ready for tomorrow's unpredictable demands. Aruba Virtual Stacking Framework (VSF) allows for stacking of up to 10 switches, providing scale and simplified management. This flexible series has built-in highspeed uplinks and supports high density IEEE 802.3bt high power PoE with HPE Smart Rate multi-gigabit Ethernet for high speed APs and IoT devices.
Technical Specifications
| Primary Information | |
| Network Device Type: | Switch |
| Model: | Aruba CX 6300 Switch Series |
| Form Factor: | 1U |
| Connectivity Technology: | Wired |
| Data Transfer Rate: | 1 Gbps |
| Networking / Ports Qty: | 31 |
| Data Link Protocol: | Gigabit Ethernet |
| Processor / Type: | ARM Cortex A72 |
| RAM / Total Installed Size: | 8 GB |
| Flash Memory / Installed Size: | 32 GB |
| Power Consumption Operational: | 49 Watt |
| Max Power Consumption: | 49 Watt |
| Power / Voltage Required: | 100-240 VAC |
| Features: | Stackable Layer 3 switches with BGP, EVPN, VXLAN, VRF, and OSPF with robust security and QoS. Now supporting MACsec 256, PTP, AVB and LRM. |
| Network | |
| Power Over Ethernet (PoE) Support: | Yes |
| Remote Management Protocol: | SNMP |
| Routing Protocol: | Layer 3 Advanced |
| 10/100/1000BASE-T Ports: | 24 |
| SFP Ports: | 4 |
| Interfaces: | (24) 10/100/1000 BASE-T ports, (4) 1/10/25/50G SFP ports |
| Interfaces / Ports | |
| Interfaces: | (24) 10/100/1000 BASE-T ports, (4) 1/10/25/50G SFP ports |
| 10/100/1000BASE-T Ports: | 24 |
| SFP Ports: | 4 |
| Dimensions&Miscellaneous | |
| Width: | 1.73 Inch |
| Depth: | 17.4 Inch |
| Height: | 15.2 Inch |
| Weight: | 10.6 lbs. |
| Service&Support | |
| Service & Support Type: | See http://www.hpe.com/networking/warranty |
| Special Feature | |
| Min Operating Temperature: | 0 C |
| Max Operating Temperature: | 45 C |
| Min Storage Temperature: | -40 C |
| Max Storage Temperature: | 70 C |
| COO: | Inquire |
| TAA compliance: | Inquire |
| UNSPSC Code | |
| UNSPSC Code: | 43222612 |
