About the product
The Aruba CX 8360 v2 Switch Series offers a flexible and innovative approach to addressing the application, security, and scalability demands of the mobile, cloud, and IoT era. These switches serve the needs of the next generation core and aggregation layer of campuses, as well as virtual and cloud data center environments. The first switch in this series is the Aruba CX 8360-48Y6C v2 switch.
Technical Specifications
| Primary Information | |
| Network Device Type: | Switch |
| Model: | Aruba CX 8360 v2 Switch Series |
| Form Factor: | 1U |
| Data Transfer Rate: | 1 Gbps |
| Networking / Ports Qty: | 58 |
| Data Link Protocol: | Gigabit Ethernet |
| Processor / Type: | Quad-core |
| RAM / Total Installed Size: | 16 GB |
| Flash Memory / Installed Size: | 32 GB |
| Power / Device Type: | Power Supply |
| Power / Installed Qty: | 2 |
| Power Consumption Operational: | 725 Watt |
| Max Power Consumption: | 725 Watt |
| Power / Voltage Required: | 7.1A for 100-127 VAC 3.4A for 200-240 VAC |
| Features: | 48 ports of 100M/1GbE/10GBASE-T4 ports of 40GbE/100GbE |
| Interfaces / Ports | |
| Interfaces: | 44 ports of 1GbE/10GbE/25GbE (SFP/SFP+/SFP28) 4 ports of 10GbE/25GbE (SFP+/SFP28) with MACsec 4 ports of 40GbE/100GbE (QSFP+/QSFP28) 2 ports of 40GbE/100GbE (QSFP+/QSFP28) with MACsec |
| SFP Ports: | yes |
| SFP+ Ports: | yes |
| Network | |
| Routing Protocol: | Layer 3 Advanced |
| SFP Ports: | yes |
| SFP+ Ports: | yes |
| Interfaces: | 44 ports of 1GbE/10GbE/25GbE (SFP/SFP+/SFP28) 4 ports of 10GbE/25GbE (SFP+/SFP28) with MACsec 4 ports of 40GbE/100GbE (QSFP+/QSFP28) 2 ports of 40GbE/100GbE (QSFP+/QSFP28) with MACsec |
| Dimensions&Miscellaneous | |
| Width: | 1.73 Inch |
| Depth: | 17.4 Inch |
| Height: | 22 Inch |
| Weight: | 23.65 lbs. |
| Service&Support | |
| Service & Support Type: | Limited Lifetime Warranty |
| Special Feature | |
| Min Operating Temperature: | 0 celsius |
| Max Operating Temperature: | 45 celsius |
| Min Storage Temperature: | -40 Celsius |
| Max Storage Temperature: | 70 Celsius |
| COO: | Inquire |
| TAA compliance: | Inquire |
| UNSPSC Code | |
| UNSPSC Code: | 43222612 |
