Hpe Aruba Networking Cx 6200F 24G 4Sfp+ Switch - Switch - Max. Sta

Name: Hpe Aruba Networking Cx 6200F 24G 4Sfp+ Switch - Switch - Max. Sta
Brand: Ilo
SKU: T932388
Price: 5884.60 CAD
Availability: InStock

$5,884.60 CAD

~~$6,473.06 CAD~~ $5,884.60 CAD

-9% OFF Ask for quote

Shipping calculated at checkout.

Hpe Aruba Networking Cx 6200F 24G 4Sfp+ Switch - Switch - Max. Stacking Distance 10 Kms - 24 Ports - Managed - Rack-Mountable

VPN:JL724B#ABA SKU:T932388 UPC:190017637921

Quantity

Volume discount available - Ask for quote..

View full details

Product information summary

Hpe Aruba Networking Cx 6200F 24G 4Sfp+ Switch - Switch - Max. Sta

About the product

The HPE Aruba Networking CX 6200 Switch Series is a next-gen family of stackable access switches ideal for enterprise branch offices, campuses, and SMB networks. With a cloud-centric design that combines a fully programmable OS with the HPE Aruba Network Analytics Engine, the HPE Aruba Networking CX 6200 extends industry-leading monitoring and troubleshooting capabilities to the access layer. Support of Aruba NetEdit and the Aruba CX Mobile App verify that configurations are flawless and easy to deploy. Make your network ready for tomorrow's unpredictable demands with a powerful Aruba Gen7 ASIC architecture to deliver fast, non-blocking performance. Aruba Virtual Stacking Framework (VSF) allows for stacking of up to 8 switches, providing scale and simplified management. This series includes fixed (CX 6200F) and modular (CX 6200M) switches with built-in high speed uplinks and up to 1440W of PoE to support IoT devices such as security cameras and wireless APs.

Technical Specifications

Primary Information
Product Description:	HPE Aruba Networking CX 6200F 24G 4SFP+ Switch - switch - Max. Stacking Distance 10 kms - 24 ports - managed - rack-mountable
Device Type:	Switch - 24 ports - L3 - managed - stackable
Enclosure Type:	Front and side to back rack-mountable 1U
Subtype:	Gigabit Ethernet
Ports:	24 x 10/100/1000 + 4 x 100/1000/10G SFP+
Performance:	Switching capacity: 128 Gbps ¦ Throughput: 95.2 Mpps ¦ Latency (1 Gbps): 2.28 µs ¦ Latency (10 Gbps): 1.46 µs ¦ Stacking bandwidth: 40 Gbps
Capacity:	Packet buffer size: 8 MB ¦ IPv4 ACL entries (ingress): 5120 ¦ IPv6 ACL entries (ingress): 1280 ¦ MAC ACL entries (ingress): 5120 ¦ IPv4 ACL entries (egress): 2048 ¦ IPv6 ACL entries (egress): 512 ¦ MAC ACL entries (egress): 2048 ¦ IPv4 host table capacity: 8192 ¦ IPv6 host table capacity: 8192 ¦ IPv4 routes (Unicast): 2048 ¦ IPv6 routes (Unicast): 1024 ¦ IGMP groups: 1024 ¦ MLD groups: 1024
MAC Address Table Size:	32768 entries
Jumbo Frame Support:	9220 bytes
Routing Protocol:	RIP-2, IGMPv2, IGMP, OSPFv2, IGMPv3, OSPFv3, MLDv2, MLD
Remote Management Protocol:	RMON, CLI, MIB
Features:	VRRP support, UDLD, DWRR, CoS, ToS, BPDU, RPVST+, LLDP, UTM, EQS, Address Resolution Protocol
Compliant Standards:	IEEE 802.3, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.1w, IEEE 802.1s, IEEE 802.1t, IEEE 802.1v, IEEE 802.1ab (LLDP), IEEE 802.1ak, IEEE 802.1AX
Power:	AC 100-120/200-240 V (50/60 Hz)
Dimensions (WxDxH):	17.4 in x 11.2 in x 1.7 in
Weight:	8.31 lbs
System Requirements:	AOS-CX
Localization:	English / United States
Manufacturer Warranty:	Limited lifetime warranty
General
Device Type:	Switch - 24 ports - L3 - managed - stackable
Enclosure Type:	Front and side to back rack-mountable 1U
Subtype:	Gigabit Ethernet
Ports:	24 x 10/100/1000 + 4 x 100/1000/10G SFP+
Performance:	Switching capacity: 128 Gbps ¦ Throughput: 95.2 Mpps ¦ Latency (1 Gbps): 2.28 µs ¦ Latency (10 Gbps): 1.46 µs ¦ Stacking bandwidth: 40 Gbps
Capacity:	Packet buffer size: 8 MB ¦ IPv4 ACL entries (ingress): 5120 ¦ IPv6 ACL entries (ingress): 1280 ¦ MAC ACL entries (ingress): 5120 ¦ IPv4 ACL entries (egress): 2048 ¦ IPv6 ACL entries (egress): 512 ¦ MAC ACL entries (egress): 2048 ¦ IPv4 host table capacity: 8192 ¦ IPv6 host table capacity: 8192 ¦ IPv4 routes (Unicast): 2048 ¦ IPv6 routes (Unicast): 1024 ¦ IGMP groups: 1024 ¦ MLD groups: 1024
MAC Address Table Size:	32768 entries
Jumbo Frame Support:	9220 bytes
Max Units In A Stack:	8
Routing Protocol:	RIP-2, IGMPv2, IGMP, OSPFv2, IGMPv3, OSPFv3, MLDv2, MLD
Remote Management Protocol:	RMON, CLI, MIB
Encryption Algorithm:	SSL, FIPS 140-2
Authentication Method:	Secure Shell (SSH), RADIUS, TACACS+, Secure Shell v.2 (SSH2)
Features:	VRRP support, UDLD, DWRR, CoS, ToS, BPDU, RPVST+, LLDP, UTM, EQS, Address Resolution Protocol
Compliant Standards:	IEEE 802.3, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.1w, IEEE 802.1s, IEEE 802.1t, IEEE 802.1v, IEEE 802.1ab (LLDP), IEEE 802.1ak, IEEE 802.1AX
Processor:	1 x ARM Cortex-A72: 1.8 GHz
RAM:	8 GB DDR4 SDRAM
Flash Memory:	16 GB
Expansion / Connectivity
Interfaces:	24 x 10/100/1000 Base-T RJ-45 ¦ 4 x 100/1000/10G SFP+ uplink/stacking ¦ 1 x USB-C console ¦ 1 x console RJ-45 ¦ 1 x management ¦ 1 x USB Type A host
Power
Power Device:	Internal power supply
Voltage Required:	AC 100-120/200-240 V (50/60 Hz)
80 PLUS Certification:	80 PLUS Silver
Miscellaneous
Included Accessories:	2-Post Rack Kit
Compliant Standards:	EN 61000-3-2, IEC 61000-3-2, IEC 61000-3-3, IEC 61000-4-11, IEC 61000-4-2, IEC 61000-4-3, IEC 61000-4-4, IEC 61000-4-5, IEC 61000-4-6, IEC 61000-4-8, EN 61000-3-3, Laser Class 1, EN 61000-3-3:2013, EN 60825-1:2014, IEC 62368-1: 2014 Second Edition, EN 62368-1:2014+A11:2017, EN 61000-3-2:2019, IEC 60825-1:2014 Class 1, CISPR 35: 2016, UL 62368-1 Third Edition, EN 62368-1:2020+A11:2020, KS C 9832, IEC 62368-1:2018 Third Edition, EN 55035:2017+A11:2020, CNS 15598-1:2020, CNS 15936: 2020 Class A, CAN/CSA C22.2 No. 62368-1:19 Third Edition, GB 4943.1-2022, EN 55032:2015 /A11:2020, Class A, FCC 47 CFR part 15B:2021 Class A, ICES-003 Issue 7: 2020 Class A, VCCI-CISPR 32 Class A, CISPR 32:2016 Class A, AS/NZS CISPR 32:2015 Class A
Localization:	English / United States
Software / System Requirements
OS Required:	AOS-CX
Dimensions & Weight
Width:	17.4 in
Depth:	11.2 in
Height:	1.7 in
Weight:	8.31 lbs
