About the product
HPE Networking Instant On Switch 1830 series provides an easy to use and affordable wired solution for networks supporting IT, mobile, and cloud applications. This affordable and easy-to-deploy smart-managed switch series is ideal for small businesses?looking for cost-effective wired infrastructure to keep up?with evolving network demands.?These entry-level, smart-managed switches?offer?Layer 2 switching capabilities,?Gigabit connectivity, along with flexible management modes - all at an affordable price point. With a flexible management dashboard, Power over Ethernet (PoE) options, and energy-efficient features, these switches deliver a solid business network for SMBs with limited budgets.
Technical Specifications
| Primary Information | |
| Product Description: | HPE Networking Instant On 1830 48G 24p Class4 PoE 4SFP 370W Switch - switch - 48 ports - smart - rack-mountable |
| Device Type: | Switch - 48 ports - smart |
| Enclosure Type: | Rack-mountable 1U |
| Subtype: | Gigabit Ethernet |
| Ports: | 24 x 10/100/1000 + 24 x 10/100/1000 (PoE+) + 4 x Gigabit SFP |
| Power Over Ethernet (PoE): | PoE+ |
| PoE Budget: | 370 W |
| Performance: | Latency (100 Mbps): 5.2 µs ¦ Latency (1 Gbps): 2.8 µs ¦ Throughput: 77.37 Mpps ¦ Switching capacity: 104 Gbps |
| MAC Address Table Size: | 16000 entries |
| Jumbo Frame Support: | 9216 bytes |
| Routing Protocol: | IGMP, IGMPv2 |
| Remote Management Protocol: | HTTP, HTTPS, ICMP, SNMP 1, SNMP 2c, SCP, TFTP |
| Features: | Auto-sensing per device, 1.5MB packet buffer, wall mountable, Cable Diagnostics Function, event log, Syslog support, dual image support, EEE, SCP, Global Storm Control, BPDU Filter, DoS protection, flow control, IGMP snooping, Link Aggregation, LLDP support, loop protection, port mirroring, STP support, TPM, VLAN support, Port Scheduling, auto-negotiation, auto-uplink (auto MDI/MDI-X), CoS, cloud managed, DHCP client, firmware upgradable, QoS, SNTP support |
| Compliant Standards: | IEEE 802.1p, IEEE 802.1Q, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad (LACP), IEEE 802.3u, IEEE 802.3x, IEEE 802.3z, IEEE 802.1ab (LLDP), IEEE 802.1D, IEEE 802.1w, IEEE 802.3ac, IEEE 802.3af, IEEE 802.3az, IEEE 802.3at |
| Power: | AC 100-240 V (50/60 Hz) |
| Dimensions (WxDxH): | 17.4 in x 13.8 in x 1.7 in |
| Weight: | 10.89 lbs |
| Localization: | English / United States |
| Manufacturer Warranty: | Limited lifetime warranty |
| General | |
| Device Type: | Switch - 48 ports - smart |
| Enclosure Type: | Desktop, rack-mountable 1U |
| Subtype: | Gigabit Ethernet |
| Ports: | 24 x 10/100/1000 + 24 x 10/100/1000 (PoE+) + 4 x Gigabit SFP |
| Power Over Ethernet (PoE): | PoE+ |
| PoE Budget: | 370 W |
| Performance: | Latency (100 Mbps): 5.2 µs ¦ Latency (1 Gbps): 2.8 µs ¦ Throughput: 77.37 Mpps ¦ Switching capacity: 104 Gbps |
| MAC Address Table Size: | 16000 entries |
| Jumbo Frame Support: | 9216 bytes |
| Routing Protocol: | IGMP, IGMPv2 |
| Remote Management Protocol: | HTTP, HTTPS, ICMP, SNMP 1, SNMP 2c, SCP, TFTP |
| Encryption Algorithm: | SSL |
| Features: | Auto-sensing per device, 1.5MB packet buffer, wall mountable, Cable Diagnostics Function, event log, Syslog support, dual image support, EEE, SCP, Global Storm Control, BPDU Filter, DoS protection, flow control, IGMP snooping, Link Aggregation, LLDP support, loop protection, port mirroring, STP support, TPM, VLAN support, Port Scheduling, auto-negotiation, auto-uplink (auto MDI/MDI-X), CoS, cloud managed, DHCP client, firmware upgradable, QoS, SNTP support |
| Compliant Standards: | IEEE 802.1p, IEEE 802.1Q, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad (LACP), IEEE 802.3u, IEEE 802.3x, IEEE 802.3z, IEEE 802.1ab (LLDP), IEEE 802.1D, IEEE 802.1w, IEEE 802.3ac, IEEE 802.3af, IEEE 802.3az, IEEE 802.3at |
| Processor: | 1 x ARM: 800 MHz |
| RAM: | 512 MB SDRAM |
| Flash Memory: | 256 MB |
| Status Indicators: | Port status, link/activity, speed, port duplex mode |
| Expansion / Connectivity | |
| Interfaces: | 24 x 1000Base-T RJ-45 ¦ 4 x Gigabit LAN SFP ¦ 24 x 1000Base-T RJ-45 PoE+ |
| Power | |
| Power Device: | Internal power supply |
| Voltage Required: | AC 100-240 V (50/60 Hz) |
| Power Consumption Operational: | 462.5 Watt |
| Miscellaneous | |
| MTBF: | 83.5 years |
| Compliant Standards: | AS/NZS CISPR 32 Class A, CAN/CSA C22.2 No. 62368-1 Second Edition, CAN/CSA-C22.2 No. 62368-1 Third Edition, CISPR 32 Class A, CISPR 35, CNS 13438 Class A, EN 55032:2015, EN 55035, FCC CFR47 Part 15 B Class A 2018, ICES-003 Class A, IEC 61000-3-2, IEC 61000-3-3, IEC 62368-1 Second Edition, IEC 62368-1 Third Edition, IEC/EN 60825-1:2014 Class 1, IEC/EN60950-1:2006 +A11:2009 +A1:2010 +A12:2011 +A2:2013, KN32 Class A, KN35, UL 62368-1 Second Edition, UL 62368-1 Third Edition, IEC/EN 61000-4-11, IEC/EN 61000-4-2, IEC/EN 61000-4-3, IEC/EN 61000-4-4, IEC/EN 61000-4-5, IEC/EN 61000-4-6, IEC/EN 61000-4-8, EN 61000-3-3 |
| Localization: | English / United States |
| Dimensions & Weight | |
| Width: | 17.4 in |
| Depth: | 13.8 in |
| Height: | 1.7 in |
| Weight: | 10.89 lbs |
| Manufacturer Warranty | |
| Service & Support: | Limited warranty - lifetime ¦ Technical support - live chat - lifetime ¦ Technical support - phone consulting - 90 days from date of purchase |
