About the product
Kingston's KSM48R40BS8-16MD is a 2G x 80-bit (16GB) DDR5-4800 CL40 SDRAM (Synchronous DRAM), 1Rx8, ECC, memory module, based on ten 2G x 8-bit FBGA components. The SPD is programmed to JEDEC standard latency DDR5-4800 timing of 40-39-39 at 1.1V. Each 288-pin DIMM uses gold contact fingers. The electrical and mechanical specifications are as follows:
- Power Supply: VDD = 1.1V Typical
- VDDQ = 1.1V Typical
- VPP = 1.8V Typical
- VDDSPD = 1.8V to 2.0V
- On-Die ECC
- x80 ECC (x40, 2 independent I/O sub channels)
- 32 internal banks
- Hard/Soft Post Package Repair
- Sideband access with I3C/I2C
- PCB: Height 1.23" (31.25mm)
- RoHS Compliant and Halogen-Free
Technical Specifications
| Miscellaneous | |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| Physical Characteristics | |
| Number of Pins | 288-pin |
| Thickness | 68.90 mil (1.75 mm) |
| Form Factor | DIMM |
| Length | 1.23" (31.23 mm) |
| Width | 5.25" (133.35 mm) |
| General Information | |
| Product Type | RAM Module |
| Manufacturer Part Number | KSM48R40BS8-16MD |
| Manufacturer Website Address | http://www.kingston.com |
| Manufacturer | Kingston Technology Company |
| Product Name | RAM Module |
| Brand Name | Kingston |
| Technical Information | |
| CAS Latency | CL40 |
| Device Supported | Computer |
| Error Checking | ECC |
| Number of Modules | 1 x 16GB |
| Signal Processing | Registered |
| Memory Size | 16 GB |
| Memory Technology | DDR5 SDRAM |
| Memory Standard | DDR5-4800/PC5-38400 |
| Memory Voltage | 1.10 V |
| Memory Rank | Single-rank |
